SN75LVDS386DGGR
Texas Instruments
Tape & Reel (TR); Cut Tape (CT)0°C~70°CReceiver
Ref. price$6.0720
Lead time on requestGet quote
Texas Instruments SN75LVDS Series
82 variants · Texas Instruments
About the Texas Instruments SN75LVDS Series
The Texas Instruments SN75LVDS Series series groups 82 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount, protocol of LVDS and voltage of 3V ~ 3.6V. Variants differ by case, data rate and duplex, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Texas Instruments SN75LVDS Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 16-SOIC (0.154\", 3.90mm Width) · 16-TSSOP (0.173\", 4.40mm Width) · 56-TFSOP (0.240\", 6.10mm Width) · 64-TFSOP (0.240\", 6.10mm Width)
- Data rate
- - · 155Mbps · 630Mbps
- Duplex
- - · Full
- Number of drivers (Receivers)
- 0/5 · 2/2 · 4/0 · 5/0 · 16/0
- Operating temperature
- -10°C ~ 70°C · 0°C~70°C
- Package
- Tape & Reel (TR) · Tube
- Type
- Driver · Receiver · Transceiver
Shared specifications
- Mounting
- Surface Mount
- Protocol
- LVDS
- Voltage
- 3V ~ 3.6V
Variant comparison
| Parameter | SN75LVDS31D | SN75LVDS387DGG | SN75LVDS391D | SN75LVDS391PW | SN75LVDS82DGG | SN75LVDS83BDGG |
|---|---|---|---|---|---|---|
| Case | 16-SOIC (0.154\", 3.90mm Width) | 64-TFSOP (0.240\", 6.10mm Width) | 16-SOIC (0.154\", 3.90mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 56-TFSOP (0.240\", 6.10mm Width) | 56-TFSOP (0.240\", 6.10mm Width) |
| Data rate | 155Mbps | 630Mbps | 630Mbps | 630Mbps | - | - |
| Duplex | - | - | - | - | - | - |
| Number of drivers (Receivers) | 4/0 | 16/0 | 4/0 | 4/0 | 0/5 | 5/0 |
| Operating temperature | 0°C~70°C | 0°C~70°C | 0°C~70°C | 0°C~70°C | 0°C~70°C | -10°C ~ 70°C |
| Package | Tube | Tube | Tube | Tube | Tube | Tube |
| Type | Driver | Driver | Driver | Driver | Receiver | Driver |
Request a quote on any Texas Instruments SN75LVDS Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
