STM32F100C4T6B
STMicroelectronics
2V ~ 3.6VTray-40°C ~ 85°C (TA)
Ref. price$4.3500
Lead time on requestGet quote ›
STMicroelectronics STM3 Series
205 variants · STMicroelectronics
About the STMicroelectronics STMicroelectronics STM3 Series series
The STMicroelectronics STMicroelectronics STM3 Series series groups 205 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of ARM® Cortex®-M3, core size of 32-Bit Single-Core and EEPROM size of -. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 48-LQFP · 64-LQFP
- Connectivity
- I2C, IrDA, LINbus, SPI, UART/USART · I²C, IrDA, LINbus, SPI, UART/USART
- Data converters
- A/D 10x12b; D/A 2x12b · A/D 16x12b; D/A 2x12b
- Number of i (O)
- 37 · 51
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 105°C (TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tray
- Program memory size
- 16KB (16K x 8) · 32KB (32K x 8) · 64KB (64K x 8) · 128KB (128K x 8) · 256KB (256K x 8)
- RAM size
- 4K x 8 · 8K x 8 · 24K x 8
Variant comparison
| Parameter | STM32F100C4T6B | STM32F100C4T6BTR | STM32F100C6T6B | STM32F100C8T6B | STM32F100C8T6BTR | STM32F100C8T7B |
|---|---|---|---|---|---|---|
| Case | 48-LQFP | 48-LQFP | 48-LQFP | 48-LQFP | 48-LQFP | 48-LQFP |
| Connectivity | I²C, IrDA, LINbus, SPI, UART/USART | I2C, IrDA, LINbus, SPI, UART/USART | I²C, IrDA, LINbus, SPI, UART/USART | I²C, IrDA, LINbus, SPI, UART/USART | I²C, IrDA, LINbus, SPI, UART/USART | I²C, IrDA, LINbus, SPI, UART/USART |
| Data converters | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b |
| Number of i (O) | 37 | 37 | 37 | 37 | 37 | 37 |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray |
| Program memory size | 16KB (16K x 8) | 16KB (16K x 8) | 32KB (32K x 8) | 64KB (64K x 8) | 64KB (64K x 8) | 64KB (64K x 8) |
| RAM size | 4K x 8 | 4K x 8 | 4K x 8 | 8K x 8 | 8K x 8 | 8K x 8 |
Shared specifications
- Core processor
- ARM® Cortex®-M3
- Core size
- 32-Bit Single-Core
- EEPROM size
- -
- Mounting type
- Surface Mount
- Oscillator type
- Internal
- Peripherals
- DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT
- Program memory type
- FLASH
- Speed
- 24MHz
- Voltage - supply (Vcc (Vdd))
- 2V ~ 3.6V
Request a quote on any STMicroelectronics STM3 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the STMicroelectronics STMicroelectronics STM3 Series variants differ?
- STMicroelectronics STM3 Series part numbers differ by case, connectivity, data converters and number of i (O). Use the selection guide above to pick by case.
- How many STMicroelectronics STMicroelectronics STM3 Series part numbers are listed?
- 205 STMicroelectronics STMicroelectronics STM3 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for STMicroelectronics STMicroelectronics STM3 Series?
- Request a quote (RFQ) for any STMicroelectronics STM3 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
