D5V0F1U2S9Q-7
Diodes Incorporated
Tape & Reel (TR); Cut Tape (CT)-55°C~150°C(TJ)Zener
Ref. price$0.4200
Lead time on requestGet quote
Diodes Incorporated D5V0 Series
71 variants · Diodes Incorporated
About the Diodes Incorporated D5V0 Series
The Diodes Incorporated D5V0 Series series groups 71 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by applications, capacitance @ frequency and case, so you can match the exact applications your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Diodes Incorporated D5V0 Series variants and discontinued ones from a single page.
Select a variant by
- Applications
- - · Automotive, HDMI, USB · General Purpose · Telecom
- Capacitance @ frequency
- 0.3pF @ 1MHz · 0.5pF @ 1MHz · 8pF @ 1MHz · 15pF @ 1MHz · 85pF @ 1MHz · 100pF @ 1MHz · 156pF @ 1MHz
- Case
- 6-UFDFN · 0201 (0603 Metric) · 0402 (1006 Metric) · SOD-923 · SOT-23-5 Thin, TSOT-23-5 · TO-236-3, SC-59, SOT-23-3
- Current - peak pulse (10/1000μs)
- 1.5A (8/20µs) · 4A (8/20µs) · 6A (8/20µs) · 15A (8/20µs) · 25A (8/20µs) · 30A (8/20µs) · 40A
- Operating temperature
- -65°C ~ 150°C (TJ) · -65°C~150°C(TJ) · -55°C ~ 125°C (TJ) · -55°C ~ 150°C (TJ) · -55°C~150°C(TJ)
- Package
- Bulk · Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Power - peak pulse
- - · 84W · 300W · 375W · 440W
- Power line protection
- No · Yes
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | D5V0F1U2S9Q-7 | D5V0F2U6LP-7 | D5V0H1B2LPQ-7B | D5V0HA2U3SO-7 | D5V0L2B3SO-7 | D5V0L4B5TS-7 |
|---|---|---|---|---|---|---|
| Applications | Automotive, HDMI, USB | General Purpose | - | Telecom | General Purpose | General Purpose |
| Capacitance @ frequency | 0.5pF @ 1MHz | 0.5pF @ 1MHz | 85pF @ 1MHz | 156pF @ 1MHz | 15pF @ 1MHz | 15pF @ 1MHz |
| Case | SOD-923 | 6-UFDFN | 0402 (1006 Metric) | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | SOT-23-5 Thin, TSOT-23-5 |
| Current - peak pulse (10/1000μs) | 1.5A (8/20µs) | 1.5A (8/20µs) | 25A (8/20µs) | 15A (8/20µs) | 6A (8/20µs) | 6A (8/20µs) |
| Operating temperature | -55°C~150°C(TJ) | -55°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) | -55°C ~ 125°C (TJ) | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Bulk | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Power - peak pulse | - | - | 375W | 300W | 84W | 84W |
| Power line protection | No | Yes | No | No | No | No |
Request a quote on any Diodes Incorporated D5V0 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
