TPS2051BD
Texas Instruments
Not RequiredTube-40°C~125°C(TJ)
Ref. price$1.1300
Lead time on requestGet quote ›
Texas Instruments TPS2 Series
321 variants · Texas Instruments
About the Texas Instruments Texas Instruments TPS2 Series series
The Texas Instruments Texas Instruments TPS2 Series series groups 321 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by package, case and current - output, so you can match the exact package your application requires using the selection guide below.
Select a variant by
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP (0.173\", 4.40mm Width) · 8-VDFN Exposed Pad · SC-74A, SOT-753
- Current - output
- 1.25A · 2A · 500mA
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C~85°C · -40°C~125°C(TJ)
- Ratio - Input:Output
- 1:1 · 2:1
- Fault protection
- Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO · Current Limiting (Fixed), Over Temperature, UVLO
- Features
- Load Discharge, Status Flag · Output Discharge · Status Flag
Variant comparison
| Parameter | TPS2051BD | TPS2051BDBVR | TPS2051BDBVT | TPS2051BDR | TPS2051CDBVR | TPS2051CDBVT |
|---|---|---|---|---|---|---|
| Package | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Case | 8-SOIC (0.154\", 3.90mm Width) | SC-74A, SOT-753 | SC-74A, SOT-753 | 8-SOIC (0.154\", 3.90mm Width) | SC-74A, SOT-753 | SC-74A, SOT-753 |
| Current - output | 500mA | 500mA | 500mA | 500mA | 500mA | 500mA |
| Operating temperature | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C ~ 85°C (TA) |
| Ratio - Input:Output | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 |
| Fault protection | Current Limiting (Fixed), Over Temperature, UVLO | Current Limiting (Fixed), Over Temperature, UVLO | Current Limiting (Fixed), Over Temperature, UVLO | Current Limiting (Fixed), Over Temperature, UVLO | Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO | Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO |
| Features | Status Flag | Status Flag | Status Flag | Status Flag | Load Discharge, Status Flag | Output Discharge |
Request a quote on any Texas Instruments TPS2 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Texas Instruments Texas Instruments TPS2 Series variants differ?
- Texas Instruments TPS2 Series part numbers differ by package, case, current - output and operating temperature. Use the selection guide above to pick by package.
- How many Texas Instruments Texas Instruments TPS2 Series part numbers are listed?
- 321 Texas Instruments Texas Instruments TPS2 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Texas Instruments Texas Instruments TPS2 Series?
- Request a quote (RFQ) for any Texas Instruments TPS2 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
