SN74ACT72231L20RJ
Texas Instruments
Bulk
Ref. price$15.93
Lead time on requestGet quote
SN74xx Standard Logic Gates & Flip-Flops
86 variants · Texas Instruments
About the SN74xx Standard Logic Gates & Flip-Flops
The Texas Instruments SN74xx Standard Logic Gates & Flip-Flops series groups 86 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by case, mounting and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 6-TSSOP, SC-88, SOT-363 · 8-VFSOP (0.091\", 2.30mm Width) · 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · 20-DIP (0.300\", 7.62mm) · 20-SOIC (0.209\", 5.30mm Width) · 20-SSOP (0.209\", 5.30mm Width) · 20-TSSOP (0.173\", 4.40mm Width) · 24-TSSOP (0.173\", 4.40mm Width) · 48-TFSOP (0.240\", 6.10mm Width) · SC-74A, SOT-753
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 85°C (TA) · -40°C ~ 125°C (TA) · 0°C ~ 70°C (TA)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 0.8V ~ 3.6V · 1.2V ~ 3.6V · 1.65V ~ 5.5V · 2V ~ 6V · 4.5V ~ 5.5V · 4.75V ~ 5.25V
- Current - output high, low
- -, 4mA · -, 24mA · -, 40mA · 4mA, 4mA · 6mA, 6mA · 7.8mA, 7.8mA · 12mA, 12mA · 32mA, 64mA
- Logic type
- Buffer, Inverting · Buffer, Non-Inverting · Inverter · Transceiver, Non-Inverting · Translation Transceiver
Variant comparison
| Parameter | SN74ABT244APWR | SN74AUP1G240DBVT | SN74AUP2G126DCUR | SN74CBTD16210DGGR | SN74HCT245NSR | SN74LS07DR |
|---|---|---|---|---|---|---|
| Case | 20-TSSOP (0.173\", 4.40mm Width) | SC-74A, SOT-753 | 8-VFSOP (0.091\", 2.30mm Width) | 48-TFSOP (0.240\", 6.10mm Width) | 20-SOIC (0.209\", 5.30mm Width) | 14-SOIC (0.154\", 3.90mm Width) |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C | -40°C ~ 85°C (TA) | 0°C ~ 70°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Voltage | 4.5V ~ 5.5V | 0.8V ~ 3.6V | 0.8V ~ 3.6V | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.75V ~ 5.25V |
| Current - output high, low | 32mA, 64mA | 4mA, 4mA | 4mA, 4mA | — | 6mA, 6mA | -, 40mA |
| Logic type | Buffer, Non-Inverting | Buffer, Inverting | Buffer, Non-Inverting | — | Transceiver, Non-Inverting | Buffer, Non-Inverting |
Request a quote on any SN74xx Standard Logic Gates & Flip-Flops part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
