LMH6502MAX/NOPB
Texas Instruments
LMH®Bulk-40°C ~ 85°C
Ref. price$5.93
Lead time on requestGet quote
Texas Instruments LMH6 Logic Series
28 variants · Texas Instruments
About the Texas Instruments LMH6 Logic Series
The Texas Instruments LMH6 Logic Series series groups 28 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, package and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-WFDFN Exposed Pad · 14-SOIC (0.154\", 3.90mm Width) · 16-WFQFN Exposed Pad · 32-WFQFN Exposed Pad · 54-WFQFN Exposed Pad
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT)
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 125°C
- -3db bandwidth
- 1.05 GHz · 95 MHz · 130 MHz · 150 MHz · 600 MHz · 900 MHz
- Amplifier type
- Buffer · Current Feedback · Variable Gain · Voltage Feedback
- Current - supply
- 10mA · 11mA · 12mA · 27mA · 29.1mA · 107mA
- Type
- ADC Driver · Differential · Driver · Variable Gain Amplifier
- Voltage - supply span
- 5.25 V · 10 V · 12 V
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | LMH6502MAX/NOPB | LMH6504MAX/NOPB | LMH6515SQ | LMH6517SQE/NOPB | LMH6517SQ/NOPB | LMH6521SQE/NOPB |
|---|---|---|---|---|---|---|
| Case | 14-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 16-WFQFN Exposed Pad | 32-WFQFN Exposed Pad | 32-WFQFN Exposed Pad | 32-WFQFN Exposed Pad |
| Package | Bulk | Bulk | Bulk | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | — | — | — |
| -3db bandwidth | 130 MHz | 150 MHz | 600 MHz | — | — | — |
| Amplifier type | Variable Gain | Variable Gain | Variable Gain | — | — | — |
| Current - supply | 27mA | 11mA | 107mA | — | — | — |
| Type | — | — | — | ADC Driver | ADC Driver | Variable Gain Amplifier |
| Voltage - supply span | 12 V | 12 V | 5.25 V | — | — | — |
Request a quote on any Texas Instruments LMH6 Logic Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
