CD40102BPW
Texas Instruments
Surface MountTube-55°C ~ 105°C
Ref. price$1.58
Lead time on requestGet quote
Texas Instruments CD40 Analog Series
59 variants · Texas Instruments
About the Texas Instruments CD40 Analog Series
The Texas Instruments CD40 Analog Series series groups 59 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by case, mounting and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 14-SOIC (0.154\", 3.90mm Width) · 16-DIP (0.300\", 7.62mm) · 16-SOIC (0.154\", 3.90mm Width) · 16-SOIC (0.295\", 7.50mm Width) · 16-TSSOP (0.173\", 4.40mm Width)
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -55°C ~ 105°C · -55°C ~ 125°C · -55°C ~ 125°C (TA)
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 3 V ~ 18 V · 3V ~ 18V
- Current - output high, low
- 3mA, 36mA · 3.4mA, 3.4mA · 4.3mA, 24mA · 6.8mA, 6.8mA · 8mA, 48mA
- Logic type
- BCD Counter · Buffer, Non-Inverting · Inverter · NAND Gate
Variant comparison
| Parameter | CD40102BPW | CD4010BM | CD4023BM | CD4027BPW | CD4049UBD | CD4049UBDT |
|---|---|---|---|---|---|---|
| Case | 16-TSSOP (0.173\", 4.40mm Width) | 16-SOIC (0.154\", 3.90mm Width) | 14-SOIC (0.154\", 3.90mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 16-SOIC (0.154\", 3.90mm Width) | 16-SOIC (0.154\", 3.90mm Width) |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating temperature | -55°C ~ 105°C | -55°C ~ 125°C (TA) | -55°C ~ 125°C | -55°C ~ 125°C (TA) | -55°C ~ 125°C | -55°C ~ 125°C |
| Package | Tube | Tube | Bulk | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) |
| Voltage | 3 V ~ 18 V | 3V ~ 18V | 3V ~ 18V | 3V ~ 18V | 3V ~ 18V | 3V ~ 18V |
| Current - output high, low | — | 3mA, 36mA | 3.4mA, 3.4mA | 6.8mA, 6.8mA | 4.3mA, 24mA | 4.3mA, 24mA |
| Logic type | BCD Counter | Buffer, Non-Inverting | NAND Gate | — | Inverter | Inverter |
Request a quote on any Texas Instruments CD40 Analog Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
