BTS3011TEATMA1
Infineon Technologies
3V ~ 5.5VOn/OffAutomotive, AEC-Q100
Ref. price$2.6700
Lead time on requestGet quote ›
Infineon Technologies BTS3 Series
24 variants · Infineon Technologies
About the Infineon Technologies Infineon Technologies BTS3 Series series
The Infineon Technologies Infineon Technologies BTS3 Series series groups 24 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common input type of Non-Inverting, mounting type of Surface Mount and number of outputs of 1. Variants differ by case, current - output and fault protection, so you can match the exact case your application requires using the selection guide below. All listed Infineon Technologies BTS3 Series part numbers are active and orderable.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) Exposed Pad · TO-252-3, DPak (2 Leads + Tab), SC-63 · TO-252-3, DPAK (2 Leads + Tab), SC-63 · TO-252-5, DPak (4 Leads + Tab), TO-252AD · TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Current - output
- 2A · 3A · 4A · 5A · 6A · 10A
- Fault protection
- Current Limiting (Fixed), Over Temperature, Over Voltage · Over Current, Over Voltage, Short Circuit
- Features
- - · Auto Restart
- Interface
- On/Off · PWM
- Rds on
- 10.7mOhm · 18mOhm · 28mOhm · 30mOhm · 44mOhm · 50mOhm · 69mOhm · 80mOhm · 104mOhm
- Voltage - load
- 3V ~ 28V · 31V (Max) · 40V (Max) · 42V (Max) · 60V (Max)
Variant comparison
| Parameter | BTS3011TEATMA1 | BTS3018TCATMA1 | BTS3028SDLATMA1 | BTS3035EJXUMA1 | BTS3035TFATMA1 | BTS3050EJXUMA1 |
|---|---|---|---|---|---|---|
| Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | TO-252-3, DPak (2 Leads + Tab), SC-63 | 8-SOIC (0.154\", 3.90mm Width) Exposed Pad | TO-252-3, DPak (2 Leads + Tab), SC-63 | 8-SOIC (0.154\", 3.90mm Width) Exposed Pad |
| Current - output | 10A | 6A | 5A | 5A | 5A | 4A |
| Fault protection | Over Current, Over Voltage, Short Circuit | Current Limiting (Fixed), Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage | Current Limiting (Fixed), Over Temperature, Over Voltage |
| Features | - | - | - | Auto Restart | Auto Restart | Auto Restart |
| Interface | On/Off | On/Off | On/Off | On/Off | On/Off | On/Off |
| Rds on | 10.7mOhm | 18mOhm | 28mOhm | 30mOhm | 30mOhm | 44mOhm |
| Voltage - load | 3V ~ 28V | 60V (Max) | 60V (Max) | 40V (Max) | 40V (Max) | 40V (Max) |
Shared specifications
- Input type
- Non-Inverting
- Mounting type
- Surface Mount
- Number of outputs
- 1
- Operating temperature
- -40°C ~ 150°C (TJ)
- Output configuration
- Low Side
- Output type
- N-Channel
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Ratio - Input:Output
- 1:1
- Switch type
- General Purpose
Request a quote on any Infineon Technologies BTS3 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Infineon Technologies Infineon Technologies BTS3 Series variants differ?
- Infineon Technologies BTS3 Series part numbers differ by case, current - output, fault protection and features. Use the selection guide above to pick by case.
- How many Infineon Technologies Infineon Technologies BTS3 Series part numbers are listed?
- 24 Infineon Technologies Infineon Technologies BTS3 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Infineon Technologies Infineon Technologies BTS3 Series?
- Request a quote (RFQ) for any Infineon Technologies BTS3 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
