TMS320F28021DAS
Texas Instruments
C2000™ C28x Piccolo™Tray40MHz
Ref. price$6.8400
Lead time on requestGet quote
TMS320F28 C2000 Real-Time MCU
455 variants · Texas Instruments
About the TMS320F28 C2000 Real-Time MCU
The Texas Instruments TMS320F28 C2000 Real-Time MCU series groups 455 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of C28x, core size of 32-Bit Single-Core and EEPROM size of -. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 38-TSSOP (0.240\", 6.10mm Width) · 48-LQFP · 80-LQFP · 100-LFBGA · 100-LQFP
- Connectivity
- CANbus, I2C, McBSP, SCI, SPI, UART/USART · CANbus, I²C, SCI, SPI, UART/USART · I²C, SCI, SPI, UART/USART
- Data converters
- A/D 7x12b · A/D 8x12b · A/D 12x12b · A/D 13x12b · A/D 16x12b
- Number of i (O)
- 20 · 22 · 35 · 40
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C ~ 125°C (TA) · -40°C~85°C(TA) · -40°C~105°C(TA) · -40°C~125°C(TA)
- Package
- Tray · Tube
- Peripherals
- Brown-out Detect/Reset, DMA, POR, PWM, WDT · Brown-out Detect/Reset, POR, PWM, WDT · POR, PWM, WDT
- Program memory size
- 32KB (16K x 16) · 64KB (32K x 16) · 128KB (64K x 16)
Shared specifications
- Core processor
- C28x
- Core size
- 32-Bit Single-Core
- EEPROM size
- -
- Mounting
- Surface Mount
- Oscillator type
- Internal
- Program memory type
- FLASH
Variant comparison
| Parameter | TMS320F28021DAS | TMS320F28027DAS | TMS320F28062FPNT | TMS320F2806PZA | TMS320F28015NMFA | TMS320F28015PZA |
|---|---|---|---|---|---|---|
| Case | 38-TSSOP (0.240\", 6.10mm Width) | 38-TSSOP (0.240\", 6.10mm Width) | 80-LQFP | 100-LQFP | 100-LFBGA | 100-LQFP |
| Connectivity | I²C, SCI, SPI, UART/USART | I²C, SCI, SPI, UART/USART | CANbus, I2C, McBSP, SCI, SPI, UART/USART | CANbus, I²C, SCI, SPI, UART/USART | CANbus, I²C, SCI, SPI, UART/USART | I²C, SCI, SPI, UART/USART |
| Data converters | A/D 7x12b | A/D 7x12b | A/D 12x12b | A/D 16x12b | A/D 16x12b | A/D 16x12b |
| Number of i (O) | 20 | 20 | 40 | 35 | 35 | 35 |
| Operating temperature | -40°C~125°C(TA) | -40°C~125°C(TA) | -40°C ~ 105°C (TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) |
| Package | Tray | Tube | Tray | Tray | Tray | Tray |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, DMA, POR, PWM, WDT | POR, PWM, WDT | POR, PWM, WDT | POR, PWM, WDT |
| Program memory size | 64KB (32K x 16) | 64KB (32K x 16) | 128KB (64K x 16) | 64KB (32K x 16) | 32KB (16K x 16) | 32KB (16K x 16) |
Request a quote on any TMS320F28 C2000 Real-Time MCU part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
