Vishay — Signal Isolation

Turnkey BOM procurement and spot-buy shortage sourcing for Vishay Signal Isolation — 93 part numbers with specifications and datasheets. Filter by key specs and

title
6N136-X007T · 6N136-X009T · BRT13H · CNY117-3
Turn On / Turn Off Time (Typ)
200ns, 200ns · 3µs, 2.3µs · 5µs, 3µs · 6µs, 5µs
Current Transfer Ratio (Min)
19% @ 16mA · 100% @ 10mA · 160% @ 10mA · 50% @ 5mA
Package / Case
8-SMD, Gull Wing · 6-DIP (0.300", 7.62mm) · 4-SMD, Gull Wing · 4-EDIP (0.300", 7.62mm)
Rise / Fall Time (Typ)
2µs, 2µs · 2.4µs, 2.7µs · 3µs, 4.7µs · 3µs, 3.7µs
Supplier Device Package
8-SMD · 6-DIP · 4-SMD · 4-DIP
Voltage - Forward (Vf) (Typ)
1.33V · 1.1V · 1.39V · 1.32V
Current Transfer Ratio (Max)
200% @ 10mA · 320% @ 10mA · 150% @ 5mA · 125% @ 10mA
