TPS51120RHBR
Texas Instruments
Surface MountD-CAP™Tape & Reel (TR); Cut Tape (CT)
Ref. price$3.97
Lead time on requestGet quote
TPS5xxx Voltage Supervisors & Battery Chargers
29 variants · Texas Instruments
About the TPS5xxx Voltage Supervisors & Battery Chargers
The Texas Instruments TPS5xxx Voltage Supervisors & Battery Chargers series groups 29 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, I/O channels and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-PowerSOIC (0.154\", 3.90mm Width) · 8-SOIC (0.154\", 3.90mm Width) · 10-VFDFN Exposed Pad · 14-TSSOP (0.173\", 4.40mm Width) Exposed Pad · 16-VFQFN Exposed Pad · 24-TSSOP (0.173\", 4.40mm Width) · 24-VFQFN Exposed Pad · 32-VFQFN Exposed Pad · 40-WFQFN Exposed Pad
- I/O channels
- 1 · 2
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C · -40°C ~ 150°C (TJ)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Output type
- Adjustable · Transistor Driver
- Synchronous rectifier
- No · Yes
- Frequency
- 1.1MHz · 300kHz · 350kHz · 630kHz · 700kHz
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | TPS51120RHBR | TPS51125ARGET | TPS53125PW | TPS53311RGTT | TPS53659RSBT | TPS54226PWP |
|---|---|---|---|---|---|---|
| Case | 32-VFQFN Exposed Pad | 24-VFQFN Exposed Pad | 24-TSSOP (0.173\", 4.40mm Width) | 16-VFQFN Exposed Pad | 40-WFQFN Exposed Pad | 14-TSSOP (0.173\", 4.40mm Width) Exposed Pad |
| I/O channels | 2 | 2 | 2 | 1 | 2 | 1 |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 125°C | -40°C ~ 85°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube |
| Output type | Transistor Driver | Transistor Driver | Transistor Driver | Adjustable | — | Adjustable |
| Synchronous rectifier | Yes | Yes | Yes | Yes | — | Yes |
| Frequency | — | — | 350kHz | 1.1MHz | — | 700kHz |
Request a quote on any TPS5xxx Voltage Supervisors & Battery Chargers part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
