AQY206GVY
Panasonic Electric Works
Surface MountPhotoMOS™ AQYTape & Reel (TR)
Ref. price$10.0081
Lead time on requestGet quote
Panasonic Electric Works AQY2 Series
199 variants · Panasonic Electric Works
About the Panasonic Electric Works AQY2 Series
The Panasonic Electric Works AQY2 Series series groups 199 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common circuit of SPST-NO (1 Form A). Variants differ by case, load current and mounting, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 4-DIP (0.300\", 7.62mm) · 4-SMD (0.116\", 2.95mm) · 4-SMD (0.175\", 4.45mm) · 4-SMD (0.300\", 7.62mm) · 4-SMD, Flat Leads · 4-SOP (0.173\", 4.40mm)
- Load current
- 1 A · 1.1 A · 50 mA · 100 mA · 120 mA · 150 mA · 400 mA · 500 mA · 550 mA
- Mounting
- Surface Mount · Through Hole
- On-State resistance
- 2.5 Ohms · 12.5 Ohms · 15 Ohms · 25 Ohms · 35 Ohms · 120 Ohms · 500 mOhms · 700 mOhms
- Output type
- AC, DC · AC, DC (RF)
- Package
- Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Termination style
- Gull Wing · PC Pin · SMD (SMT) Tab
- Voltage - input
- 1.14VDC · 1.32VDC · 1.47 ~ 1.7VDC
Shared specifications
- Circuit
- SPST-NO (1 Form A)
Variant comparison
| Parameter | AQY206GVY | AQY210HLA | AQY210LSZ | AQY211EHA | AQY212EH | AQY212GHAX |
|---|---|---|---|---|---|---|
| Case | 4-SMD, Flat Leads | 4-SMD (0.300\", 7.62mm) | 4-SOP (0.173\", 4.40mm) | 4-SMD (0.300\", 7.62mm) | 4-DIP (0.300\", 7.62mm) | 4-SMD (0.300\", 7.62mm) |
| Load current | 150 mA | 120 mA | 120 mA | 1 A | 550 mA | 1.1 A |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole | Surface Mount |
| On-State resistance | 15 Ohms | 25 Ohms | 25 Ohms | 500 mOhms | 2.5 Ohms | 700 mOhms |
| Output type | AC, DC | AC, DC | AC, DC | AC, DC | AC, DC | AC, DC |
| Package | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tube | Tube | Tape & Reel (TR) Cut Tape (CT) |
| Termination style | SMD (SMT) Tab | Gull Wing | Gull Wing | Gull Wing | PC Pin | Gull Wing |
| Voltage - input | 1.47 ~ 1.7VDC | 1.14VDC | 1.14VDC | 1.14VDC | 1.14VDC | 1.14VDC |
Request a quote on any Panasonic Electric Works AQY2 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
