MCP1801T-1202I/OT
Microchip Technology
Surface Mount-40°C ~ 85°C< 1 A
Ref. price$0.56
Lead time on requestGet quote
MCP1xxx Power Supervisors, Voltage References & MOSFET Drivers
290 variants · Microchip Technology
About the MCP1xxx Power Supervisors, Voltage References & MOSFET Drivers
The Microchip Technology MCP1xxx Power Supervisors, Voltage References & MOSFET Drivers series groups 290 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount, number of regulators of 1 and output configuration of Positive. Variants differ by case, current - quiescent and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- SC-74A, SOT-753 · TO-261-4, TO-261AA
- Current - quiescent
- 50 µA · 220 µA
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 125°C
- Output current
- 150mA · 300mA
- Protection features
- Over Current · Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
- PSRR
- 55dB (100Hz) · 70dB (10kHz)
- Voltage - input
- 6V · 10V
- Voltage - output (Min (Fixed))
- 1.2V · 5V
Shared specifications
- Mounting
- Surface Mount
- Number of regulators
- 1
- Output configuration
- Positive
- Output type
- Fixed
- Package
- Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | MCP1801T-1202I/OT | MCP1824ST-5002E/DB |
|---|---|---|
| Case | SC-74A, SOT-753 | TO-261-4, TO-261AA |
| Current - quiescent | 50 µA | 220 µA |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 125°C |
| Output current | 150mA | 300mA |
| Protection features | Over Current | Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
| PSRR | 70dB (10kHz) | 55dB (100Hz) |
| Voltage - input | 10V | 6V |
| Voltage - output (Min (Fixed)) | 1.2V | 5V |
Request a quote on any MCP1xxx Power Supervisors, Voltage References & MOSFET Drivers part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
