SN65LVDS047DR
Texas Instruments
65LVDSDriver-40°C~85°C
Ref. price$4.2400
Lead time on requestGet quote
SN65LVDS 3.3V LVDS Interface IC—Drivers Receivers Transceivers SerDes
304 variants · Texas Instruments
About the SN65LVDS 3.3V LVDS Interface IC—Drivers Receivers Transceivers SerDes
The Texas Instruments SN65LVDS 3.3V LVDS Interface IC—Drivers Receivers Transceivers SerDes series groups 304 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, data rate and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) · 16-SOIC (0.154\", 3.90mm Width) · 16-TSSOP (0.173\", 4.40mm Width) · 64-TFSOP (0.240\", 6.10mm Width) · 80-VFBGA
- Data rate
- 1.755Gbps · 2Gbps · 150Mbps · 400Mbps
- Operating temperature
- -40°C~85°C · -40°C~85°C(TA)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 1.65V ~ 1.95V · 3V ~ 3.6V
- Type
- Buffer, Multiplexer · Buffer, ReDriver · Receiver · Transceiver
- Capacitance - input
- 0.6 pF · 3 pF · 5 pF
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | SN65LVDS048AD | SN65LVDS049PW | SN65LVDS049PWR | SN65LVDS050PW | SN65LVDS100DGK | SN65LVDS101DGK |
|---|---|---|---|---|---|---|
| Case | 16-SOIC (0.154\", 3.90mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) | 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) |
| Data rate | 400Mbps | 400Mbps | 400Mbps | 400Mbps | 2Gbps | 2Gbps |
| Operating temperature | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C |
| Package | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube | Tube |
| Voltage | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V |
| Type | Receiver | Transceiver | Transceiver | Transceiver | Buffer, ReDriver | Buffer, ReDriver |
| Capacitance - input | — | — | — | — | 0.6 pF | 0.6 pF |
Request a quote on any SN65LVDS 3.3V LVDS Interface IC—Drivers Receivers Transceivers SerDes part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
