LPC5506JHI48QL
NXP USA Inc.
Tray-40°C ~ 105°C (TA)96MHz
Ref. price$5.9100
Lead time on requestGet quote ›
NXP Semiconductors LPC55 Series
18 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors LPC55 Series series
The NXP Semiconductors NXP Semiconductors LPC55 Series series groups 18 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common core processor of ARM® Cortex®-M33, oscillator type of Internal and program memory type of FLASH. Variants differ by case, connectivity and core size, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors LPC55 Series part numbers are active and orderable.
Select a variant by
- Case
- 48-VFQFN Exposed Pad · 64-TQFP Exposed Pad · 98-VFBGA · 100-LQFP Exposed Pad
- Connectivity
- CANbus, Flexcomm, I²C, I²S, I³C, SPI, UART/USART · CANBus, Flexcomm, I²C, SPI, UART/USART · CANbus, Flexcomm, I²C, SPI, UART/USART, USB · Flexcomm, I²C, MMC/SD/SDIO, SPI, UART/USART, USB · Flexcomm, I²C, SPI, UART/USART, USB
- Core size
- 32-Bit · 32-Bit Single-Core
- Data converters
- A/D 7x16b SAR · A/D 10x16b · A/D 10x16b SAR
- Mounting type
- Surface Mount · Surface Mount, Wettable Flank
- Number of i (O)
- 30 · 32 · 36 · 64
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C~105°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tray
Variant comparison
| Parameter | LPC5506JHI48QL | LPC5512JBD64E | LPC5514JBD64E | LPC5516JBD100Y | LPC5516JBD64E | LPC5526JBD100K |
|---|---|---|---|---|---|---|
| Case | 48-VFQFN Exposed Pad | 64-TQFP Exposed Pad | 64-TQFP Exposed Pad | 100-LQFP Exposed Pad | 64-TQFP Exposed Pad | 100-LQFP Exposed Pad |
| Connectivity | CANBus, Flexcomm, I²C, SPI, UART/USART | CANbus, Flexcomm, I²C, SPI, UART/USART, USB | CANbus, Flexcomm, I²C, SPI, UART/USART, USB | Flexcomm, I²C, SPI, UART/USART, USB | CANbus, Flexcomm, I²C, SPI, UART/USART, USB | Flexcomm, I²C, MMC/SD/SDIO, SPI, UART/USART, USB |
| Core size | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit | 32-Bit Single-Core | 32-Bit Single-Core |
| Data converters | A/D 7x16b SAR | A/D 10x16b SAR | A/D 10x16b SAR | A/D 10x16b SAR | A/D 10x16b SAR | A/D 10x16b |
| Mounting type | Surface Mount, Wettable Flank | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Number of i (O) | 30 | 36 | 36 | 64 | 36 | 64 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C~105°C(TA) | -40°C~105°C(TA) | -40°C ~ 105°C (TA) | -40°C~105°C(TA) | -40°C~105°C(TA) |
| Package | Tray | Tray | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray | Tray |
Shared specifications
- Core processor
- ARM® Cortex®-M33
- Oscillator type
- Internal
- Program memory type
- FLASH
- Voltage - supply (Vcc (Vdd))
- 1.8V ~ 3.6V
Request a quote on any NXP Semiconductors LPC55 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the NXP Semiconductors NXP Semiconductors LPC55 Series variants differ?
- NXP Semiconductors LPC55 Series part numbers differ by case, connectivity, core size and data converters. Use the selection guide above to pick by case.
- How many NXP Semiconductors NXP Semiconductors LPC55 Series part numbers are listed?
- 18 NXP Semiconductors NXP Semiconductors LPC55 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for NXP Semiconductors NXP Semiconductors LPC55 Series?
- Request a quote (RFQ) for any NXP Semiconductors LPC55 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
