TPS3103E12DBVR
Texas Instruments
Tape & Reel (TR); Cut Tape (CT)-40°C~85°C(TJ)Simple Reset/Power-On Reset
Ref. price$2.9000
Lead time on requestGet quote ›
Texas Instruments TPS3 Series
296 variants · Texas Instruments
About the Texas Instruments Texas Instruments TPS3 Series series
The Texas Instruments Texas Instruments TPS3 Series series groups 296 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of SOT-23-6, mounting type of Surface Mount and number of voltages monitored of 1. Variants differ by operating temperature, output and package, so you can match the exact operating temperature your application requires using the selection guide below.
Select a variant by
- Operating temperature
- -40°C ~ 85°C (TJ) · -40°C~85°C(TJ)
- Output
- Open Drain or Open Collector · Push-Pull, Totem Pole
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Voltage - threshold
- 0.86V · 1.142V · 1.434V · 1.521V · 1.84V · 2.941V
Variant comparison
| Parameter | TPS3103E12DBVR | TPS3103E12DBVT | TPS3103E15DBVR | TPS3103E15DBVT | TPS3103H20DBVT | TPS3106E09DBVR |
|---|---|---|---|---|---|---|
| Operating temperature | -40°C~85°C(TJ) | -40°C~85°C(TJ) | -40°C~85°C(TJ) | -40°C~85°C(TJ) | -40°C~85°C(TJ) | -40°C~85°C(TJ) |
| Output | Open Drain or Open Collector | Open Drain or Open Collector | Open Drain or Open Collector | Open Drain or Open Collector | Open Drain or Open Collector | Open Drain or Open Collector |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Voltage - threshold | 1.142V | 1.142V | 1.434V | 1.434V | 1.84V | 0.86V |
Shared specifications
- Case
- SOT-23-6
- Mounting type
- Surface Mount
- Number of voltages monitored
- 1
- Reset
- Active Low
- Reset timeout
- 65ms Minimum
- Type
- Simple Reset/Power-On Reset
Request a quote on any Texas Instruments TPS3 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Texas Instruments Texas Instruments TPS3 Series variants differ?
- Texas Instruments TPS3 Series part numbers differ by operating temperature, output, package and voltage - threshold. Use the selection guide above to pick by operating temperature.
- How many Texas Instruments Texas Instruments TPS3 Series part numbers are listed?
- 296 Texas Instruments Texas Instruments TPS3 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Texas Instruments Texas Instruments TPS3 Series?
- Request a quote (RFQ) for any Texas Instruments TPS3 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
