LMK00334RTVTQ1
Texas Instruments
3.15V ~ 3.45VTape & Reel (TR); Cut Tape (CT)-40°C~105°C
Ref. price$3.5800
Lead time on requestGet quote ›
Texas Instruments LMK0 Series
17 variants · Texas Instruments
About the Texas Instruments Texas Instruments LMK0 Series series
The Texas Instruments Texas Instruments LMK0 Series series groups 17 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting type of Surface Mount and number of circuits of 1. Variants differ by case, differential - Input:Output and frequency, so you can match the exact case your application requires using the selection guide below. All listed Texas Instruments LMK0 Series part numbers are active and orderable.
Select a variant by
- Case
- 16-TSSOP (0.173\", 4.40mm Width) · 32-WFQFN Exposed Pad · 48-WFQFN Exposed Pad
- Differential - Input:Output
- Yes/No · Yes/Yes
- Frequency
- 1.08GHz · 1.296GHz · 1.57GHz · 1.6 GHz · 1.724GHz · 1.75GHz · 2.16GHz · 350 MHz · 400MHz
- Input
- Clock · CML, HCSL, HSTL, LVDS, LVPECL, SSTL, Crystal · LVCMOS, LVDS, LVPECL · LVCMOS, LVTTL
- Operating temperature
- -40°C~85°C · -40°C~85°C(TA) · -40°C~105°C
- Output
- 2VPECL, LVPECL · HCSL, LVCMOS · HCSL, LVCMOS, LVDS, LVHSTL, LVPECL, LVTTL, SSTL · LVCMOS, 2VPECL, LVPECL · LVCMOS, LVDS, 2VPECL, LVPECL · LVDS · LVDS, LVPECL · LVPECL
- Package
- Tape & Reel (TR) · Tape & Reel (TR); Cut Tape (CT)
- Ratio - Input:Output
- 1:4 · 1:8 · 2:5 · 2:6 · 2:7 · 3:5
Variant comparison
| Parameter | LMK00334RTVTQ1 | LMK00804BPWR | LMK01010ISQ/NOPB | LMK03000DISQE/NOPB | LMK03000DISQ/NOPB | LMK03002ISQX/NOPB |
|---|---|---|---|---|---|---|
| Case | 32-WFQFN Exposed Pad | 16-TSSOP (0.173\", 4.40mm Width) | 48-WFQFN Exposed Pad | 48-WFQFN Exposed Pad | 48-WFQFN Exposed Pad | 48-WFQFN Exposed Pad |
| Differential - Input:Output | Yes/Yes | Yes/No | Yes/Yes | Yes/Yes | Yes/Yes | Yes/Yes |
| Frequency | 400MHz | 350 MHz | 1.6 GHz | 1.296GHz | 1.296GHz | 1.724GHz |
| Input | CML, HCSL, HSTL, LVDS, LVPECL, SSTL, Crystal | LVCMOS, LVTTL | Clock | LVCMOS, LVDS, LVPECL | LVCMOS, LVDS, LVPECL | LVCMOS, LVDS, LVPECL |
| Operating temperature | -40°C~105°C | -40°C~85°C(TA) | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C |
| Output | HCSL, LVCMOS | HCSL, LVCMOS, LVDS, LVHSTL, LVPECL, LVTTL, SSTL | LVDS | LVDS, LVPECL | LVDS, LVPECL | LVPECL |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Ratio - Input:Output | 3:5 | 1:4 | 1:8 | 1:8 | 1:8 | 1:4 |
Shared specifications
- Mounting type
- Surface Mount
- Number of circuits
- 1
Request a quote on any Texas Instruments LMK0 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Texas Instruments Texas Instruments LMK0 Series variants differ?
- Texas Instruments LMK0 Series part numbers differ by case, differential - Input:Output, frequency and input. Use the selection guide above to pick by case.
- How many Texas Instruments Texas Instruments LMK0 Series part numbers are listed?
- 17 Texas Instruments Texas Instruments LMK0 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Texas Instruments Texas Instruments LMK0 Series?
- Request a quote (RFQ) for any Texas Instruments LMK0 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
