MOC3020M
onsemi
Tube-40°C ~ 85°CTriac
Ref. price$0.6800
Lead time on requestGet quote ›
onsemi MOC30 Series
46 variants · onsemi
About the onsemi onsemi MOC30 Series series
The onsemi onsemi MOC30 Series series groups 46 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common current - DC forward (If) of 60 mA, number of channels of 1 and output type of Triac. Variants differ by approval agency, case and current - hold, so you can match the exact approval agency your application requires using the selection guide below.
Select a variant by
- Approval agency
- IEC/EN/DIN, UL · UL · UR, VDE
- Case
- 6-DIP (0.300\", 7.62mm) · 6-DIP (0.400\", 10.16mm) · 6-SMD, Gull Wing
- Current - hold
- 100µA (Typ) · 220µA (Typ) · 400µA (Typ)
- Current - LED trigger (Ift)
- 5mA · 10mA · 15mA · 30mA
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C · -40°C~85°C
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tube
- Static dV (dt)
- - · 1kV/µs
Variant comparison
| Parameter | MOC3020M | MOC3020SM | MOC3020SR2M | MOC3021TVM | MOC3022SR2M | MOC3022SR2VM |
|---|---|---|---|---|---|---|
| Approval agency | UL | UL | UL | IEC/EN/DIN, UL | UL | IEC/EN/DIN, UL |
| Case | 6-DIP (0.300\", 7.62mm) | 6-SMD, Gull Wing | 6-SMD, Gull Wing | 6-DIP (0.400\", 10.16mm) | 6-SMD, Gull Wing | 6-SMD, Gull Wing |
| Current - hold | 100µA (Typ) | 100µA (Typ) | 100µA (Typ) | 100µA (Typ) | 100µA (Typ) | 100µA (Typ) |
| Current - LED trigger (Ift) | 30mA | 30mA | 30mA | 15mA | 10mA | 10mA |
| Mounting type | Through Hole | Surface Mount | Surface Mount | Through Hole | Surface Mount | Surface Mount |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C~85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Package | Tube | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Static dV (dt) | - | - | - | - | - | - |
Shared specifications
- Current - DC forward (If)
- 60 mA
- Number of channels
- 1
- Output type
- Triac
- Turn on time
- -
- Voltage - isolation
- 4170Vrms
Request a quote on any onsemi MOC30 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the onsemi onsemi MOC30 Series variants differ?
- onsemi MOC30 Series part numbers differ by approval agency, case, current - hold and current - LED trigger (Ift). Use the selection guide above to pick by approval agency.
- How many onsemi onsemi MOC30 Series part numbers are listed?
- 46 onsemi onsemi MOC30 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for onsemi onsemi MOC30 Series?
- Request a quote (RFQ) for any onsemi MOC30 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
