EP4CE10E22C6
Intel
Tray0°C ~ 85°C (TJ)Cyclone® IV E
Ref. price$48.8801
Lead time on requestGet quote
EP4CE Cyclone IV E Low-Power FPGA 6K–75K Logic Elements 60nm
287 variants · Intel
About the EP4CE Cyclone IV E Low-Power FPGA 6K–75K Logic Elements 60nm
The Intel EP4CE Cyclone IV E Low-Power FPGA 6K–75K Logic Elements 60nm series groups 287 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount and package of Tray. Variants differ by case, number of i (O) and number of LABs (CLBs), so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 144-LQFP Exposed Pad · 256-LBGA · 484-BGA · 780-BGA
- Number of i (O)
- 81 · 91 · 165 · 179 · 280 · 528
- Number of LABs (CLBs)
- 645 · 963 · 7155
- Number of logic elements (Cells)
- 10320 · 15408 · 114480
- Operating temperature
- -40°C~100°C(TJ) · 0°C ~ 85°C (TJ) · 0°C~85°C(TJ)
- Total RAM bits
- 423936 · 516096 · 3981312
- Voltage
- 0.97V ~ 1.03V · 1.15V ~ 1.25V
Shared specifications
- Mounting
- Surface Mount
- Package
- Tray
Variant comparison
| Parameter | EP4CE10E22C6 | EP4CE10E22C8LN | EP4CE10E22I8L | EP4CE10F17C9LN | EP4CE115F23C7 | EP4CE115F23C9L |
|---|---|---|---|---|---|---|
| Case | 144-LQFP Exposed Pad | 144-LQFP Exposed Pad | 144-LQFP Exposed Pad | 256-LBGA | 484-BGA | 484-BGA |
| Number of i (O) | 91 | 91 | 91 | 179 | 280 | 280 |
| Number of LABs (CLBs) | 645 | 645 | 645 | 645 | 7155 | 7155 |
| Number of logic elements (Cells) | 10320 | 10320 | 10320 | 10320 | 114480 | 114480 |
| Operating temperature | 0°C ~ 85°C (TJ) | 0°C~85°C(TJ) | -40°C~100°C(TJ) | 0°C~85°C(TJ) | 0°C~85°C(TJ) | 0°C ~ 85°C (TJ) |
| Total RAM bits | 423936 | 423936 | 423936 | 423936 | 3981312 | 3981312 |
| Voltage | 1.15V ~ 1.25V | 0.97V ~ 1.03V | 0.97V ~ 1.03V | 0.97V ~ 1.03V | 1.15V ~ 1.25V | 0.97V ~ 1.03V |
Request a quote on any EP4CE Cyclone IV E Low-Power FPGA 6K–75K Logic Elements 60nm part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
