STTH102
STMicroelectronics
Cut Tape (CT); Tape & Box (TB)Fast Recovery =< 500ns, > 200mA (Io)Standard
Ref. price$0.4600
Lead time on requestGet quote ›
STMicroelectronics STTH Series
46 variants · STMicroelectronics
About the STMicroelectronics STMicroelectronics STTH Series series
The STMicroelectronics STMicroelectronics STTH Series series groups 46 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common capacitance @ vr, f of - and speed of Fast Recovery =< 500ns, > 200mA (Io). Variants differ by case, current - average rectified and current - reverse leakage @ vr, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current STMicroelectronics STTH Series variants and discontinued ones from a single page.
Select a variant by
- Case
- DO-204AC, DO-15, Axial · DO-204AL, DO-41, Axial · DO-214AC, SMA · TO-220-2 · TO-220-2 Full Pack, Isolated Tab · TO-220-2 Insulated, TO-220AC
- Current - average rectified
- 1A · 1.5A · 12A · 15A
- Current - reverse leakage @ vr
- 1 µA @ 200 V · 1 µA @ 600 V · 3 µA @ 200 V · 10 µA @ 1000 V · 15 µA @ 600 V · 30 µA @ 600 V · 45 µA @ 600 V · 60 µA @ 600 V
- Mounting type
- Surface Mount · Through Hole
- Operating temperature - junction
- 175°C (Max) · 175°C(Max)
- Package
- Cut Tape (CT) Tape & Box (TB) · Cut Tape (CT); Tape & Box (TB) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Reverse recovery time
- 20 ns · 21 ns · 30 ns · 45 ns · 50 ns · 75 ns · 80 ns · 85 ns · 90 ns
- Voltage - DC reverse (Vr)
- 200 V · 600 V · 1000 V
Variant comparison
| Parameter | STTH102 | STTH110RL | STTH1210D | STTH1210DI | STTH12R06DIRG | STTH12S06FP |
|---|---|---|---|---|---|---|
| Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | TO-220-2 | TO-220-2 Insulated, TO-220AC | TO-220-2 Insulated, TO-220AC | TO-220-2 Full Pack, Isolated Tab |
| Current - average rectified | 1A | 1A | 12A | 12A | 12A | 12A |
| Current - reverse leakage @ vr | 1 µA @ 200 V | 10 µA @ 1000 V | 10 µA @ 1000 V | 10 µA @ 1000 V | 45 µA @ 600 V | 30 µA @ 600 V |
| Mounting type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating temperature - junction | 175°C(Max) | 175°C(Max) | 175°C(Max) | 175°C(Max) | 175°C (Max) | 175°C(Max) |
| Package | Cut Tape (CT); Tape & Box (TB) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube | Tube | Tube |
| Reverse recovery time | 20 ns | 75 ns | 90 ns | 90 ns | 45 ns | 21 ns |
| Voltage - DC reverse (Vr) | 200 V | 1000 V | 1000 V | 1000 V | 600 V | 600 V |
Shared specifications
- Capacitance @ vr, f
- -
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
Request a quote on any STMicroelectronics STTH Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the STMicroelectronics STMicroelectronics STTH Series variants differ?
- STMicroelectronics STTH Series part numbers differ by case, current - average rectified, current - reverse leakage @ vr and mounting type. Use the selection guide above to pick by case.
- How many STMicroelectronics STMicroelectronics STTH Series part numbers are listed?
- 46 STMicroelectronics STMicroelectronics STTH Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for STMicroelectronics STMicroelectronics STTH Series?
- Request a quote (RFQ) for any STMicroelectronics STTH Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
