AT45DB021E-SHN2B-T
Renesas Electronics
1.65V ~ 3.6VTape & Reel (TR); Cut Tape (CT)70 MHz
Ref. price$1.35
Lead time on requestGet quote ›
Renesas Electronics AT45DB Series
49 variants · Renesas Electronics
About the Renesas Electronics Renesas Electronics AT45DB Series series
The Renesas Electronics Renesas Electronics AT45DB Series series groups 49 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common memory format of FLASH, memory interface of SPI and memory type of Non-Volatile. Variants differ by case, frequency and memory organization, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-SOIC (0.209\", 5.30mm Width) · 8-UDFN Exposed Pad · 8-UFBGA, WLCSP
- Frequency
- 70 MHz · 85 MHz
- Memory organization
- 256 Bytes x 1024 pages · 264 Bytes x 32K pages · 264 Bytes x 2048 pages · 264 Bytes x 4096 pages · 528 Bytes x 4096 pages · 528 Bytes x 8192 pages
- Memory size
- 2Mbit · 4Mbit · 8Mbit · 16Mbit · 32Mbit · 64Mbit
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT)
- Voltage
- 1.65V ~ 3.6V · 1.7V ~ 3.6V · 2.3V ~ 3.6V
- Write cycle time - word, page
- 8µs, 3ms · 8µs, 4ms · 8µs, 5ms
Variant comparison
| Parameter | AT45DB021E-SHN2B-T | AT45DB041E-SHN-T | AT45DB041E-SSHN-T | AT45DB081E-UUN-T | AT45DB161E-SSHF-B | AT45DB161E-SSHFHC-T |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.209\", 5.30mm Width) | 8-SOIC (0.209\", 5.30mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-UFBGA, WLCSP | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) |
| Frequency | 70 MHz | 85 MHz | 85 MHz | 85 MHz | 85 MHz | 85 MHz |
| Memory organization | 256 Bytes x 1024 pages | 264 Bytes x 2048 pages | 264 Bytes x 2048 pages | 264 Bytes x 4096 pages | 528 Bytes x 4096 pages | 528 Bytes x 4096 pages |
| Memory size | 2Mbit | 4Mbit | 4Mbit | 8Mbit | 16Mbit | 16Mbit |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Bulk | Tape & Reel (TR); Cut Tape (CT) |
| Voltage | 1.65V ~ 3.6V | 1.65V ~ 3.6V | 1.65V ~ 3.6V | 1.7V ~ 3.6V | 2.3V ~ 3.6V | 2.3V ~ 3.6V |
| Write cycle time - word, page | 8µs, 3ms | 8µs, 3ms | 8µs, 3ms | 8µs, 4ms | 8µs, 4ms | 8µs, 4ms |
Shared specifications
- Memory format
- FLASH
- Memory interface
- SPI
- Memory type
- Non-Volatile
- Mounting type
- Surface Mount
- Operating temperature
- -40°C ~ 85°C (TC)
- Technology
- FLASH
Request a quote on any Renesas Electronics AT45DB Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Renesas Electronics Renesas Electronics AT45DB Series variants differ?
- Renesas Electronics AT45DB Series part numbers differ by case, frequency, memory organization and memory size. Use the selection guide above to pick by case.
- How many Renesas Electronics Renesas Electronics AT45DB Series part numbers are listed?
- 49 Renesas Electronics Renesas Electronics AT45DB Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Renesas Electronics Renesas Electronics AT45DB Series?
- Request a quote (RFQ) for any Renesas Electronics AT45DB Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
