MOC3020TVM
onsemi
Tube-40°C~85°CTriac
Ref. price$0.8200
Lead time on requestGet quote ›
onsemi MOC30 Series
64 variants · onsemi
About the onsemi onsemi MOC30 Series series
The onsemi onsemi MOC30 Series series groups 64 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common current - DC forward (If) of 60 mA, current - hold of 100µA (Typ) and number of channels of 1. Variants differ by approval agency, case and current - LED trigger (Ift), so you can match the exact approval agency your application requires using the selection guide below.
Select a variant by
- Approval agency
- IEC/EN/DIN, UL · UL
- Case
- 6-DIP (0.300\", 7.62mm) · 6-DIP (0.400\", 10.16mm) · 6-SMD, Gull Wing
- Current - LED trigger (Ift)
- 5mA · 10mA · 15mA · 30mA
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C · -40°C~85°C
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
Variant comparison
| Parameter | MOC3020TVM | MOC3021M | MOC3021SM | MOC3021SR2VM | MOC3021SVM | MOC3021VM |
|---|---|---|---|---|---|---|
| Approval agency | IEC/EN/DIN, UL | UL | UL | IEC/EN/DIN, UL | IEC/EN/DIN, UL | IEC/EN/DIN, UL |
| Case | 6-DIP (0.400\", 10.16mm) | 6-DIP (0.300\", 7.62mm) | 6-SMD, Gull Wing | 6-SMD, Gull Wing | 6-SMD, Gull Wing | 6-DIP (0.300\", 7.62mm) |
| Current - LED trigger (Ift) | 30mA | 15mA | 15mA | 15mA | 15mA | 15mA |
| Mounting type | Through Hole | Through Hole | Surface Mount | Surface Mount | Surface Mount | Through Hole |
| Operating temperature | -40°C~85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C~85°C | -40°C ~ 85°C |
| Package | Tube | Tube | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube | Tube |
Shared specifications
- Current - DC forward (If)
- 60 mA
- Current - hold
- 100µA (Typ)
- Number of channels
- 1
- Output type
- Triac
- Static dV (dt)
- -
- Turn on time
- -
- Voltage - forward (Vf)
- 1.15V
- Voltage - isolation
- 4170Vrms
- Voltage - off state
- 400 V
- Zero crossing circuit
- No
Request a quote on any onsemi MOC30 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the onsemi onsemi MOC30 Series variants differ?
- onsemi MOC30 Series part numbers differ by approval agency, case, current - LED trigger (Ift) and mounting type. Use the selection guide above to pick by approval agency.
- How many onsemi onsemi MOC30 Series part numbers are listed?
- 64 onsemi onsemi MOC30 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for onsemi onsemi MOC30 Series?
- Request a quote (RFQ) for any onsemi MOC30 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
