NXP Semiconductors — Logic ICs

NXP Semiconductors Logic ICs — 103 part numbers with specifications and datasheets. Filter by key specs and request a quote on ICBOMS.

title
74AHC245PW-Q100118 · 74AHC2G241DP-Q100125 · 74AHC2G32DC-Q100125 · 74AHC2G32GD-Q100125
Supplier Device Package
8-TSSOP · 20-SO · 48-SSOP · 56-SSOP
Package / Case
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) · 20-SOIC (0.295", 7.50mm Width) · 48-BSSOP (0.295", 7.50mm Width) · 56-BSSOP (0.295", 7.50mm Width)
Logic Type
Transceiver, Non-Inverting · Buffer, Non-Inverting · AND/OR Gate · OR Gate
Current - Output High, Low
8mA, 8mA · 24mA, 24mA · 8mA, 24mA; 32mA, 64mA · 4mA, 4mA
Max Propagation Delay @ V, Max CL
3.4ns @ 3.3V, 50pF · 3.7ns @ 3.3V, 50pF · 3.1ns @ 3.3V, 50pF · 6.4ns @ 3.3V, 30pF
Voltage - Supply
4.5V ~ 5.5V · 1.65V ~ 3.6V · 1.2V ~ 3.6V · 2.3V ~ 2.7V, 3V ~ 3.6V
Number of Bits per Element
8 · 1 · 4 · 9
