SN74LVC1G06DBVR
Texas Instruments
1.65V ~ 5.5VTape & Reel (TR); Cut Tape (CT)-40°C~125°C
Ref. price$0.4000
Lead time on requestGet quote ›
Texas Instruments SN74LV Series
383 variants · Texas Instruments
About the Texas Instruments Texas Instruments SN74LV Series series
The Texas Instruments Texas Instruments SN74LV Series series groups 383 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common input type of -, mounting type of Surface Mount and number of bits per element of 1. Variants differ by case, current - output high, low and logic type, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 4-XFBGA, DSBGA · 5-TSSOP, SC-70-5, SOT-353 · 6-UFDFN · 6-XFDFN · SC-74A, SOT-753 · SOT-553
- Current - output high, low
- -, 32mA · 32mA, 32mA
- Logic type
- Buffer, Inverting · Buffer, Non-Inverting
- Operating temperature
- -55°C~125°C · -40°C ~ 125°C (TA) · -40°C~85°C(TA) · -40°C~125°C · -40°C~125°C(TA)
- Output type
- 3-State · Open Drain
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | SN74LVC1G06DBVR | SN74LVC1G06DBVT | SN74LVC1G06DRLR | SN74LVC1G06DRYR | SN74LVC1G06DSFR | SN74LVC1G06MDCKREP |
|---|---|---|---|---|---|---|
| Case | SC-74A, SOT-753 | SC-74A, SOT-753 | SOT-553 | 6-UFDFN | 6-XFDFN | 5-TSSOP, SC-70-5, SOT-353 |
| Current - output high, low | -, 32mA | -, 32mA | -, 32mA | -, 32mA | -, 32mA | -, 32mA |
| Logic type | Buffer, Inverting | Buffer, Inverting | Buffer, Inverting | Buffer, Inverting | Buffer, Inverting | Buffer, Inverting |
| Operating temperature | -40°C~125°C | -40°C~125°C | -40°C~125°C | -40°C~125°C | -40°C~125°C | -55°C~125°C |
| Output type | Open Drain | Open Drain | Open Drain | Open Drain | Open Drain | Open Drain |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
Shared specifications
- Input type
- -
- Mounting type
- Surface Mount
- Number of bits per element
- 1
- Number of elements
- 1
- Voltage
- 1.65V ~ 5.5V
Request a quote on any Texas Instruments SN74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Texas Instruments Texas Instruments SN74LV Series variants differ?
- Texas Instruments SN74LV Series part numbers differ by case, current - output high, low, logic type and operating temperature. Use the selection guide above to pick by case.
- How many Texas Instruments Texas Instruments SN74LV Series part numbers are listed?
- 383 Texas Instruments Texas Instruments SN74LV Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Texas Instruments Texas Instruments SN74LV Series?
- Request a quote (RFQ) for any Texas Instruments SN74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
