VIPER012HSTR
STMicroelectronics
4.5V ~ 30VTape & Reel (TR) Cut Tape (CT)-40°C ~ 150°C (TJ)
Ref. price$1.1500
Lead time on requestGet quote ›
STMicroelectronics VIPER Series
47 variants · STMicroelectronics
About the STMicroelectronics STMicroelectronics VIPER Series series
The STMicroelectronics STMicroelectronics VIPER Series series groups 47 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common internal switch of Yes. Variants differ by case, control features and duty cycle, so you can match the exact case your application requires using the selection guide below. All listed STMicroelectronics VIPER Series part numbers are active and orderable.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm), 7 Leads · 8-SOIC (0.154\", 3.90mm Width) · 10-SOP (0.154\", 3.90mm Width)
- Control features
- - · Soft Start
- Duty cycle
- - · 70% · 80%
- Fault protection
- Current Limiting, Open Loop, Over Temperature · Current Limiting, Over Temperature, Over Voltage · Current Limiting, Over Temperature, Over Voltage, Short Circuit · Over Load, Over Voltage
- Frequency
- 30kHz · 60kHz · 115kHz · 120kHz
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 150°C (TC) · -40°C ~ 150°C (TJ) · -40°C~150°C(TJ)
- Output isolation
- Either · Non-Isolated
Variant comparison
| Parameter | VIPER012HSTR | VIPER012LSTR | VIPER013HS | VIPER013XSTR | VIPER06HN | VIPER06LN |
|---|---|---|---|---|---|---|
| Case | 10-SOP (0.154\", 3.90mm Width) | 10-SOP (0.154\", 3.90mm Width) | 10-SOP (0.154\", 3.90mm Width) | 10-SOP (0.154\", 3.90mm Width) | 8-DIP (0.300\", 7.62mm), 7 Leads | 8-DIP (0.300\", 7.62mm), 7 Leads |
| Control features | - | - | - | - | - | - |
| Duty cycle | 80% | 80% | 80% | 80% | 70% | 70% |
| Fault protection | Current Limiting, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Open Loop, Over Temperature | Current Limiting, Open Loop, Over Temperature |
| Frequency | 120kHz | 60kHz | 120kHz | 30kHz | 115kHz | 60kHz |
| Mounting type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole | Through Hole |
| Operating temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C~150°C(TJ) | -40°C ~ 150°C (TJ) | -40°C~150°C(TJ) |
| Output isolation | Either | Either | Either | Either | Either | Either |
Shared specifications
- Internal switch
- Yes
Request a quote on any STMicroelectronics VIPER Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the STMicroelectronics STMicroelectronics VIPER Series variants differ?
- STMicroelectronics VIPER Series part numbers differ by case, control features, duty cycle and fault protection. Use the selection guide above to pick by case.
- How many STMicroelectronics STMicroelectronics VIPER Series part numbers are listed?
- 47 STMicroelectronics STMicroelectronics VIPER Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for STMicroelectronics STMicroelectronics VIPER Series?
- Request a quote (RFQ) for any STMicroelectronics VIPER Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
