onsemi NTMFS Series

53 variants · onsemi

About the onsemi onsemi NTMFS Series series

The onsemi onsemi NTMFS Series series groups 53 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common FET feature of -, FET type of N-Channel and mounting type of Surface Mount. Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current onsemi NTMFS Series variants and discontinued ones from a single page.

Select a variant by

Case
8-PowerTDFN · 8-PowerTDFN, 5 Leads
Current - continuous drain (Id) @ 25°C
9.2A (Ta), 61A (Tc) · 9.3A (Ta), 82A (Tc) · 10.5A (Ta), 54A (Tc) · 10.7A (Ta), 78A (Tc) · 11.6A (Ta), 79A (Tc) · 12A (Ta), 79A (Tc) · 19A (Ta), 142A (Tc) · 20A (Ta), 69A (Tc) · 22A (Ta), 147A (Tc) · 59A (Ta), 409A (Tc) · 60A (Ta), 433A (Tc) · 166A (Tc)
Drain to source voltage
30 V · 80 V · 100 V · 120 V · 150 V
Drive voltage (Max rds on, min rds on)
4.5V, 10V · 6V, 10V · 8V, 10V · 10V
Gate charge (Qg) (Max) @ vgs
19 nC @ 10 V · 26 nC @ 10 V · 27 nC @ 10 V · 30 nC @ 10 V · 33 nC @ 10 V · 43 nC @ 10 V · 46 nC @ 10 V · 71.3 nC @ 10 V · 73 nC @ 10 V · 84 nC @ 10 V · 145 nC @ 10 V · 147 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds
1683 pF @ 15 V · 2120 pF @ 75 V · 2300 pF @ 40 V · 2705 pF @ 60 V · 3044 pF @ 15 V · 3592 pF @ 75 V · 3900 pF @ 50 V · 5350 pF @ 40 V · 6240 pF @ 40 V · 10500 pF @ 15 V · 12300 pF @ 15 V · 13380 pF @ 50 V
Operating temperature
-55°C ~ 150°C (TJ) · -55°C ~ 175°C (TJ) · -55°C~150°C(TJ) · -55°C~175°C(TJ)
Package
Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)

Variant comparison

ParameterNTMFS006N08MCNTMFS008N12MCT1GNTMFS011N15MCNTMFS015N10MCLT1GNTMFS015N15MCNTMFS08N003C
Case8-PowerTDFN8-PowerTDFN, 5 Leads8-PowerTDFN8-PowerTDFN, 5 Leads8-PowerTDFN8-PowerTDFN
Current - continuous drain (Id) @ 25°C9.3A (Ta), 82A (Tc)12A (Ta), 79A (Tc)10.7A (Ta), 78A (Tc)10.5A (Ta), 54A (Tc)9.2A (Ta), 61A (Tc)22A (Ta), 147A (Tc)
Drain to source voltage80 V120 V150 V100 V150 V80 V
Drive voltage (Max rds on, min rds on)6V, 10V6V, 10V8V, 10V4.5V, 10V8V, 10V6V, 10V
Gate charge (Qg) (Max) @ vgs30 nC @ 10 V33 nC @ 10 V46 nC @ 10 V19 nC @ 10 V27 nC @ 10 V73 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds2300 pF @ 40 V2705 pF @ 60 V3592 pF @ 75 V13380 pF @ 50 V2120 pF @ 75 V5350 pF @ 40 V
Operating temperature-55°C~150°C(TJ)-55°C ~ 150°C (TJ)-55°C~150°C(TJ)-55°C~175°C(TJ)-55°C~150°C(TJ)-55°C~150°C(TJ)
PackageTape & Reel (TR); Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)

Shared specifications

FET feature
-
FET type
N-Channel
Mounting type
Surface Mount
Technology
MOSFET (Metal Oxide)
Vgs
±20V

Request a quote on any onsemi NTMFS Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
