LPC1758FBD80Y
NXP USA Inc.
LPC17xxTape & Reel (TR) Cut Tape (CT)Brown-out Detect/Reset, DMA, I²S, Motor Control PWM, POR, PWM, WDT
Ref. price$15.1500
Lead time on requestGet quote
LPC1 ARM Cortex-M Microcontroller
471 variants · NXP USA Inc.
About the LPC1 ARM Cortex-M Microcontroller
The NXP USA Inc. LPC1 ARM Cortex-M Microcontroller series groups 471 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core size of 32-Bit Single-Core, mounting of Surface Mount and oscillator type of Internal. Variants differ by case, connectivity and core processor, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 16-UFBGA, WLCSP · 28-TSSOP (0.173\", 4.40mm Width) · 32-VFQFN Exposed Pad · 32-VQFN Exposed Pad · 48-LQFP · 48-TFBGA
- Connectivity
- I²C, Microwire, SPI, SSI, SSP, UART/USART · I²C, SPI, UART/USART · SPI, UART/USART
- Core processor
- ARM® Cortex®-M0 · ARM® Cortex®-M0+
- Data converters
- A/D 5x10b · A/D 6x10b · A/D 8x10b · A/D 8x10b SAR · A/D 8x10b; D/A 1x10b · A/D 8x12b SAR
- Number of i (O)
- 11 · 22 · 28 · 36 · 40 · 42
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 105°C (TA) · -40°C~85°C(TA) · -40°C~105°C(TA)
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tray
- Peripherals
- Brown-out Detect/Reset, DMA, POR, PWM, WDT · Brown-out Detect/Reset, POR, WDT
Shared specifications
- Core size
- 32-Bit Single-Core
- Mounting
- Surface Mount
- Oscillator type
- Internal
- Program memory type
- FLASH
- Speed
- 50MHz
Variant comparison
| Parameter | LPC1102UK,118 | LPC1111FHN33/101551 | LPC1111FHN33/102'5 | LPC1111FHN33/203,5 | LPC1114FDH28/102:5 | LPC1114JHI33/303E |
|---|---|---|---|---|---|---|
| Case | 16-UFBGA, WLCSP | 32-VQFN Exposed Pad | 32-VQFN Exposed Pad | 32-VQFN Exposed Pad | 28-TSSOP (0.173\", 4.40mm Width) | 32-VFQFN Exposed Pad |
| Connectivity | SPI, UART/USART | I²C, SPI, UART/USART | I²C, SPI, UART/USART | I²C, SPI, UART/USART | I²C, SPI, UART/USART | I²C, SPI, UART/USART |
| Core processor | ARM® Cortex®-M0 | ARM® Cortex®-M0 | ARM® Cortex®-M0 | ARM® Cortex®-M0 | ARM® Cortex®-M0 | ARM® Cortex®-M0 |
| Data converters | A/D 5x10b | A/D 8x10b | A/D 8x10b | A/D 8x10b | A/D 6x10b | A/D 8x10b |
| Number of i (O) | 11 | 28 | 28 | 28 | 22 | 28 |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Bulk | Tape & Reel (TR); Cut Tape (CT) | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray |
| Peripherals | Brown-out Detect/Reset, POR, WDT | Brown-out Detect/Reset, POR, WDT | Brown-out Detect/Reset, POR, WDT | Brown-out Detect/Reset, POR, WDT | Brown-out Detect/Reset, POR, WDT | Brown-out Detect/Reset, POR, WDT |
Request a quote on any LPC1 ARM Cortex-M Microcontroller part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
