MAX7301AAX+
Analog Devices
Surface MountTubeSPI
Ref. price$10.77
Lead time on requestGet quote
MAX7xx µP Supervisors & Watchdog Timers
53 variants · Analog Devices
About the MAX7xx µP Supervisors & Watchdog Timers
The Analog Devices MAX7xx µP Supervisors & Watchdog Timers series groups 53 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by case, mounting and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 8-SOIC (0.154\", 3.90mm Width) · 16-SOIC (0.154\", 3.90mm Width) · 16-SSOP (0.154\", 3.90mm Width) · 24-SOIC (0.295\", 7.50mm Width) · 24-SSOP (0.154\", 3.90mm Width) · 24-SSOP (0.209\", 5.30mm Width) · 24-WFQFN Exposed Pad · 36-BSOP (0.295\", 7.50mm Width) · 40-WFQFN Exposed Pad
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C · 0°C ~ 70°C · 0°C ~ 70°C (TA)
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT) · Tube
- Interface
- 4-Wire Serial · I²C · I²C, SMBus · SPI
- Output type
- Fixed · Open Drain · Push-Pull
- Voltage
- 2V ~ 3.6V · 2V ~ 5.5V · 2.25V ~ 3.6V · 2.5V ~ 5.5V · 4V ~ 5.5V
- Current - output source (Sink)
- 4.5mA, 10mA · 20mA · 31mA, 43mA · 50mA
Variant comparison
| Parameter | MAX700CSA+ | MAX706ATESA+ | MAX706ESA+ | MAX709TEPA | MAX710ESE+ | MAX7219CWG+ |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-DIP (0.300\", 7.62mm) | 16-SOIC (0.154\", 3.90mm Width) | 24-SOIC (0.295\", 7.50mm Width) |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Through Hole | Surface Mount | Surface Mount |
| Operating temperature | 0°C ~ 70°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | 0°C ~ 70°C |
| Package | Tube | Tube | Tube | Bulk | Tube | Tube |
| Interface | — | — | — | — | — | 4-Wire Serial |
| Output type | — | — | — | — | Fixed | — |
| Voltage | — | — | — | — | — | 4V ~ 5.5V |
| Current - output source (Sink) | — | — | — | — | — | — |
Request a quote on any MAX7xx µP Supervisors & Watchdog Timers part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
