SN7416N
Texas Instruments
Through Hole7400Tube
Ref. price$2.25
Lead time on requestGet quote
SN74xx Standard Logic Gates & Flip-Flops
17 variants · Texas Instruments
About the SN74xx Standard Logic Gates & Flip-Flops
The Texas Instruments SN74xx Standard Logic Gates & Flip-Flops series groups 17 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by case, mounting and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 5-TSSOP, SC-70-5, SOT-353 · 14-DIP (0.300\", 7.62mm) · 14-SOIC (0.154\", 3.90mm Width) · 14-VFQFN Exposed Pad · 16-DIP (0.300\", 7.62mm) · 16-SOIC (0.154\", 3.90mm Width) · 20-VFQFN Exposed Pad · 28-SOIC · 48-BSSOP (0.295\", 7.50mm Width) · 48-TFSOP (0.173\", 4.40mm Width)
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 85°C (TA) · -40°C ~ 125°C · 0°C ~ 70°C
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 2V ~ 5.5V · 2.3V ~ 3.6V · 4.5 V ~ 5.5 V · 4.5V ~ 5.5V · 4.75V ~ 5.25V
- Current - output high, low
- -, 40mA · 2.6mA, 24mA · 3mA, 24mA · 8mA, 8mA · 24mA, 24mA · 32mA, 64mA
- Circuit
- 1 x 3:8 · 1 x 8:1 · 4 x 1:2 · 4 x 2:1 · 8 x 1:1 · 10 x 1:1
Variant comparison
| Parameter | SN7416N | SN74ABT16244ADGVR | SN74ACT14D | SN74ACT7201LA20DV | SN74AHC1G04DCK3 | SN74ALS151N |
|---|---|---|---|---|---|---|
| Case | 14-DIP (0.300\", 7.62mm) | 48-TFSOP (0.173\", 4.40mm Width) | 14-SOIC (0.154\", 3.90mm Width) | 28-SOIC | 5-TSSOP, SC-70-5, SOT-353 | 16-DIP (0.300\", 7.62mm) |
| Mounting | Through Hole | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole |
| Operating temperature | 0°C ~ 70°C | -40°C ~ 85°C (TA) | -40°C ~ 85°C | 0°C ~ 70°C | -40°C ~ 125°C | 0°C ~ 70°C |
| Package | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube | Bulk | Tape & Reel (TR); Cut Tape (CT) | Tube |
| Voltage | 4.75V ~ 5.25V | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.5 V ~ 5.5 V | 2V ~ 5.5V | 4.5V ~ 5.5V |
| Current - output high, low | -, 40mA | 32mA, 64mA | 24mA, 24mA | — | 8mA, 8mA | 2.6mA, 24mA |
| Circuit | — | — | — | — | — | 1 x 8:1 |
Request a quote on any SN74xx Standard Logic Gates & Flip-Flops part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
