STTH1002CB
STMicroelectronics
TubeFast Recovery =< 500ns, > 200mA (Io)Standard
Ref. price$1.2100
Lead time on requestGet quote ›
STMicroelectronics STTH Series
173 variants · STMicroelectronics
About the STMicroelectronics STMicroelectronics STTH Series series
The STMicroelectronics STMicroelectronics STTH Series series groups 173 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common speed of Fast Recovery =< 500ns, > 200mA (Io). Variants differ by case, current - reverse leakage @ vr and mounting type, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- DO-204AL, DO-41, Axial · DO-214AC, SMA · TO-220-3 · TO-220-3 Full Pack · TO-252-3, DPak (2 Leads + Tab), SC-63 · TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Current - reverse leakage @ vr
- 1 µA @ 200 V · 1 µA @ 600 V · 5 µA @ 200 V · 5 µA @ 800 V · 10 µA @ 300 V
- Mounting type
- Surface Mount · Through Hole
- Operating temperature - junction
- -40°C ~ 175°C · -40°C~175°C · 175°C (Max) · 175°C(Max)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Reverse recovery time
- 20 ns · 25 ns · 35 ns · 50 ns · 75 ns
- Voltage - DC reverse (Vr)
- 200 V · 300 V · 600 V · 800 V
Variant comparison
| Parameter | STTH1002CB | STTH1002CB-TR | STTH1002CFP | STTH1002CG-TR | STTH1002CT | STTH1003SB-TR |
|---|---|---|---|---|---|---|
| Case | TO-252-3, DPak (2 Leads + Tab), SC-63 | TO-252-3, DPak (2 Leads + Tab), SC-63 | TO-220-3 Full Pack | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | TO-220-3 | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Current - reverse leakage @ vr | 5 µA @ 200 V | 5 µA @ 200 V | 5 µA @ 200 V | 5 µA @ 200 V | 5 µA @ 200 V | 10 µA @ 300 V |
| Mounting type | Surface Mount | Surface Mount | Through Hole | Surface Mount | Through Hole | Surface Mount |
| Operating temperature - junction | 175°C (Max) | 175°C (Max) | 175°C (Max) | 175°C (Max) | 175°C (Max) | 175°C (Max) |
| Package | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube | Tape & Reel (TR) Cut Tape (CT) |
| Reverse recovery time | 25 ns | 25 ns | 25 ns | 25 ns | 25 ns | 35 ns |
| Voltage - DC reverse (Vr) | 200 V | 200 V | 200 V | 200 V | 200 V | 300 V |
Shared specifications
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
Request a quote on any STMicroelectronics STTH Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the STMicroelectronics STMicroelectronics STTH Series variants differ?
- STMicroelectronics STTH Series part numbers differ by case, current - reverse leakage @ vr, mounting type and operating temperature - junction. Use the selection guide above to pick by case.
- How many STMicroelectronics STMicroelectronics STTH Series part numbers are listed?
- 173 STMicroelectronics STMicroelectronics STTH Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for STMicroelectronics STMicroelectronics STTH Series?
- Request a quote (RFQ) for any STMicroelectronics STTH Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
