LPC2103FHN48H/6518
NXP USA Inc.
1.65V ~ 3.6VBulk-40°C~85°C(TA)
Ref. price$57.9100
Lead time on requestGet quote ›
NXP Semiconductors LPC2 Series
13 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors LPC2 Series series
The NXP Semiconductors NXP Semiconductors LPC2 Series series groups 13 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common core processor of ARM7®, core size of 16/32-Bit and mounting type of Surface Mount. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors LPC2 Series part numbers are active and orderable.
Select a variant by
- Case
- 48-VFQFN Exposed Pad · 64-LQFP · 144-LQFP · 144-TFBGA · 180-TFBGA · 208-LQFP
- Connectivity
- CANbus, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG · CANbus, EBI/EMI, I²C, Microwire, SPI, SSI, SSP, UART/USART · CANbus, I²C, Microwire, SPI, SSI, SSP, UART/USART · EBI/EMI, I²C, IrDA, Memory Card, UART/USART, USB · EBI/EMI, I²C, Microwire, SPI, SSI, SSP, UART/USART · I²C, Microwire, SPI, SSI, SSP, UART/USART
- Data converters
- - · A/D 4x10b SAR · A/D 5x10b · A/D 8x10b · A/D 8x10b SAR · A/D 8x10b SAR; D/A 1x10b · A/D 8x10b; D/A 1x10b · A/D 16x10b SAR; D/A 1x10b
- Number of i (O)
- 32 · 46 · 47 · 76 · 85 · 112 · 160
- Operating temperature
- -40°C ~ 125°C (TA) · -40°C~85°C(TA)
- Oscillator type
- External · Internal
- Package
- Bulk · Tray
- Peripherals
- Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT · Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT · Brown-out Detect/Reset, POR, PWM, WDT · DMA, I²S, LCD, WDT · POR, PWM, WDT
Variant comparison
| Parameter | LPC2103FHN48H/6518 | LPC2106FHN48/01551 | LPC2119FBD64/01EL | LPC2132FBD64/01EL | LPC2134FBD64/01EL | LPC2136FBD64/01EL |
|---|---|---|---|---|---|---|
| Case | 48-VFQFN Exposed Pad | 48-VFQFN Exposed Pad | 64-LQFP | 64-LQFP | 64-LQFP | 64-LQFP |
| Connectivity | I²C, Microwire, SPI, SSI, SSP, UART/USART | I²C, Microwire, SPI, SSI, SSP, UART/USART | CANbus, I²C, Microwire, SPI, SSI, SSP, UART/USART | I²C, Microwire, SPI, SSI, SSP, UART/USART | I²C, Microwire, SPI, SSI, SSP, UART/USART | I²C, Microwire, SPI, SSI, SSP, UART/USART |
| Data converters | A/D 8x10b | - | A/D 4x10b SAR | A/D 8x10b SAR; D/A 1x10b | A/D 16x10b SAR; D/A 1x10b | A/D 16x10b SAR; D/A 1x10b |
| Number of i (O) | 32 | 32 | 46 | 47 | 47 | 47 |
| Operating temperature | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) | -40°C~85°C(TA) |
| Oscillator type | Internal | Internal | Internal | Internal | Internal | Internal |
| Package | Bulk | Bulk | Tray | Tray | Tray | Tray |
| Peripherals | POR, PWM, WDT | POR, PWM, WDT | POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT |
Shared specifications
- Core processor
- ARM7®
- Core size
- 16/32-Bit
- Mounting type
- Surface Mount
