Infineon Technologies IRF6 Series

16 variants · Infineon Technologies

About the Infineon Technologies IRF6 Series

The Infineon Technologies IRF6 Series series groups 16 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common FET type of N-Channel and technology of MOSFET (Metal Oxide). Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below.

Select a variant by

Case: DirectFET™ Isometric MN · DirectFET™ Isometric MX · DirectFET™ Isometric MZ · DirectFET™ Isometric SJ · DirectFET™ Isometric SQ · DirectFET™ Isometric ST · TO-220-3 · TO-252-3, DPak (2 Leads + Tab), SC-63
Current - continuous drain (Id) @ 25°C: 3.4A (Ta), 19A (Tc) · 4.9A (Ta), 28A (Tc) · 5.7A (Ta), 25A (Tc) · 9.3A (Tc) · 10.3A (Ta), 60A (Tc) · 12A (Ta), 68A (Tc) · 13.4A (Ta), 67A (Tc) · 16A (Ta), 55A (Tc) · 19A (Ta), 74A (Tc) · 32A (Ta), 180A (Tc) · 58A (Tc) · 86A (Tc)
Drain to source voltage: 20 V · 25 V · 30 V · 60 V · 80 V · 100 V · 150 V · 200 V
Gate charge (Qg) (Max) @ vgs: 17 nC @ 4.5 V · 20 nC @ 10 V · 35 nC @ 10 V · 36 nC @ 10 V · 47 nC @ 10 V · 50 nC @ 10 V · 66 nC @ 10 V · 74 nC @ 4.5 V
Input capacitance (Ciss) (Max) @ vds: 575 pF @ 25 V · 890 pF @ 25 V · 1350 pF @ 25 V · 1360 pF @ 10 V · 1411 pF @ 25 V · 1500 pF @ 25 V · 1590 pF @ 13 V · 2060 pF @ 25 V · 2120 pF @ 25 V · 2170 pF @ 25 V · 2210 pF @ 25 V · 6190 pF @ 15 V
Mounting: Surface Mount · Through Hole
Operating temperature: -55°C ~ 175°C (TJ) · -40°C ~ 150°C (TJ)
Package: Bulk · Tape & Reel (TR); Cut Tape (CT) · Tube

Shared specifications

FET type: N-Channel
Technology: MOSFET (Metal Oxide)

Variant comparison

Parameter	IRF6811STRPBF-INF	IRF60R217	IRF630NPBF	IRF6623TRPBF	IRF6644TRPBF	IRF6645TRPBF
Case	DirectFET™ Isometric SQ	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-220-3	DirectFET™ Isometric ST	DirectFET™ Isometric MN	DirectFET™ Isometric SJ
Current - continuous drain (Id) @ 25°C	19A (Ta), 74A (Tc)	58A (Tc)	9.3A (Tc)	16A (Ta), 55A (Tc)	10.3A (Ta), 60A (Tc)	5.7A (Ta), 25A (Tc)
Drain to source voltage	25 V	60 V	200 V	20 V	100 V	100 V
Gate charge (Qg) (Max) @ vgs	17 nC @ 4.5 V	66 nC @ 10 V	35 nC @ 10 V	17 nC @ 4.5 V	47 nC @ 10 V	20 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds	1590 pF @ 13 V	2170 pF @ 25 V	575 pF @ 25 V	1360 pF @ 10 V	2210 pF @ 25 V	890 pF @ 25 V
Mounting	Surface Mount	Surface Mount	Through Hole	Surface Mount	Surface Mount	Surface Mount
Operating temperature	-40°C ~ 150°C (TJ)	-55°C ~ 175°C (TJ)	-55°C ~ 175°C (TJ)	-40°C ~ 150°C (TJ)	-40°C ~ 150°C (TJ)	-40°C ~ 150°C (TJ)
Package	Bulk	Tape & Reel (TR); Cut Tape (CT)	Tube	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)

Request a quote on any Infineon Technologies IRF6 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
