SN74LVC1G86MDCKREP
Texas Instruments
1.65V ~ 5.5VTape & Reel (TR); Cut Tape (CT)-55°C~125°C
Ref. price$1.9400
Lead time on requestGet quote ›
Texas Instruments SN74LV Series
340 variants · Texas Instruments
About the Texas Instruments Texas Instruments SN74LV Series series
The Texas Instruments Texas Instruments SN74LV Series series groups 340 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common current - output high, low of 32mA, 32mA, current - quiescent of 10 µA and features of -. Variants differ by case, max propagation delay @ v, max CL and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 4-XFDFN Exposed Pad · 5-TSSOP, SC-70-5, SOT-353 · 5-XFBGA, DSBGA · 6-UFDFN · 6-XFDFN · SC-74A, SOT-753 · SOT-553
- Max propagation delay @ v, max CL
- 4ns @ 5V, 50pF · 4.3ns @ 5V, 50pF · 5ns @ 5V, 50pF
- Operating temperature
- -55°C~125°C · -40°C~85°C · -40°C~125°C
Variant comparison
| Parameter | SN74LVC1G00DBVR | SN74LVC1G00DBVT | SN74LVC1G00DCKR | SN74LVC1G00DCKT | SN74LVC1G00DPWR | SN74LVC1G00DRLR |
|---|---|---|---|---|---|---|
| Case | SC-74A, SOT-753 | SC-74A, SOT-753 | 5-TSSOP, SC-70-5, SOT-353 | 5-TSSOP, SC-70-5, SOT-353 | 4-XFDFN Exposed Pad | SOT-553 |
| Max propagation delay @ v, max CL | 4.3ns @ 5V, 50pF | 4.3ns @ 5V, 50pF | 4.3ns @ 5V, 50pF | 4.3ns @ 5V, 50pF | 4.3ns @ 5V, 50pF | 4.3ns @ 5V, 50pF |
| Operating temperature | -40°C~125°C | -40°C~125°C | -40°C~125°C | -40°C~125°C | -40°C~125°C | -40°C~125°C |
Shared specifications
- Current - output high, low
- 32mA, 32mA
- Current - quiescent
- 10 µA
- Features
- -
- Input logic level - high
- 1.7V ~ 2V
- Input logic level - low
- 0.7V ~ 0.8V
- Logic type
- NAND Gate
- Mounting type
- Surface Mount
- Number of circuits
- 1
- Number of inputs
- 2
- Package
- Tape & Reel (TR); Cut Tape (CT)
- Voltage
- 1.65V ~ 5.5V
Request a quote on any Texas Instruments SN74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
