LM358ADR
Texas Instruments
Tape & Reel (TR); Cut Tape (CT)0°C~70°C(TA)0.3V/µs
Ref. price$0.3800
Lead time on requestGet quote ›
Texas Instruments LM358 Series
23 variants · Texas Instruments
About the Texas Instruments Texas Instruments LM358 Series series
The Texas Instruments Texas Instruments LM358 Series series groups 23 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common amplifier type of General Purpose and number of circuits of 2. Variants differ by case, current - input bias and current - output (Channel), so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Texas Instruments LM358 Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP (0.173\", 4.40mm Width) · 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) · SOT-23-8 · TO-99-8 Metal Can
- Current - input bias
- 10 nA · 15 nA · 15 pA · 20 nA · 45 nA
- Current - output (Channel)
- 30 mA · 40 mA
- Current - supply
- 1mA · 90µA (x2 Channels) · 300µA (x2 Channels) · 500µA (x2 Channels)
- Gain bandwidth product
- 1 MHz · 1.2 MHz · 700 kHz · 800 kHz
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 125°C · -40°C~125°C(TA) · 0°C~70°C · 0°C~70°C(TA)
- Output type
- - · Push-Pull
Variant comparison
| Parameter | LM358ADR | LM358AMX/NOPB | LM358AP | LM358APW | LM358APWR | LM358BAIDDFR |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-DIP (0.300\", 7.62mm) | 8-TSSOP (0.173\", 4.40mm Width) | 8-TSSOP (0.173\", 4.40mm Width) | SOT-23-8 |
| Current - input bias | 15 nA | 45 nA | 15 nA | 15 nA | 15 nA | 10 nA |
| Current - output (Channel) | 40 mA | 40 mA | 40 mA | 40 mA | 40 mA | 30 mA |
| Current - supply | 500µA (x2 Channels) | 1mA | 500µA (x2 Channels) | 500µA (x2 Channels) | 500µA (x2 Channels) | 300µA (x2 Channels) |
| Gain bandwidth product | 700 kHz | 1 MHz | 700 kHz | 700 kHz | 700 kHz | 1.2 MHz |
| Mounting type | Surface Mount | Surface Mount | Through Hole | Surface Mount | Surface Mount | Surface Mount |
| Operating temperature | 0°C~70°C(TA) | 0°C~70°C | 0°C~70°C(TA) | 0°C~70°C(TA) | 0°C~70°C(TA) | -40°C ~ 85°C (TA) |
| Output type | - | - | - | - | - | Push-Pull |
Shared specifications
- Amplifier type
- General Purpose
- Number of circuits
- 2
Request a quote on any Texas Instruments LM358 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Texas Instruments Texas Instruments LM358 Series variants differ?
- Texas Instruments LM358 Series part numbers differ by case, current - input bias, current - output (Channel) and current - supply. Use the selection guide above to pick by case.
- How many Texas Instruments Texas Instruments LM358 Series part numbers are listed?
- 23 Texas Instruments Texas Instruments LM358 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Texas Instruments Texas Instruments LM358 Series?
- Request a quote (RFQ) for any Texas Instruments LM358 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
