Renesas RV1S9161ACCSP-100C#KC0 high-speed optocoupler, 15 Mbps data rate, 3750 Vrms isolation, push-pull totem-pole output, 1 channel, DC input, -40 to 125°C, 6-SOIC 5-lead package.
$2.39 / ea
5 in stock — maximum per order · 3–4 days lead time
| Parameter / Attribute | Specification / Value |
|---|---|
| Input type | DC |
| Output type | Push-Pull, Totem Pole |
| Mounting | Surface Mount |
| Supply voltage | 4.5V ~ 30V |
| Voltage - isolation | 3750Vrms |
| Voltage - forward (Vf) | 1.54V |
| Current - output (Channel) | 25 mA |
| Current - DC forward (If) | 20mA |
| Operating temperature | -40°C ~ 125°C |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Data rate | 15Mbps |
| Case | 6-SOIC (0.173\", 4.40mm Width), 5 Leads |
| Channels | 1 |
| Inputs - side 1/Side 2 | 1/0 |
| Propagation delay tpLH (tpHL) | 60ns, 60ns |
| Common mode transient immunity | 100kV/µs |
Factory lead times blocking production? We lock verified brand-new original stock in Shenzhen within 2 hours.
Direct access to Shenzhen floor inventory, franchised allocation buffers, and factory bonded stock to resolve line-down shutdowns.
Standard factory-sealed packaging compliant with EIA-481 standards for automated high-speed SMT pick-and-place lines.
High-resolution photos of original reel labels, 2D DataMatrix, and pin coplanarity sent via WhatsApp/Telegram before you release wire payment.
The RV1S9161ACCSP-100C#KC0: Single-channel high-speed optocoupler rated for 15 Mbps data rate and 3750 Vrms isolation voltage. Push-pull, totem-pole output drives logic inputs directly without a pull-up resistor.
Minimum common-mode transient immunity of 100 kV/µs means the output holds state through a high dV/dt event on the isolation barrier.
This part is sourced and quoted to order through independent distribution. Submit an RFQ for current availability and pricing — no minimum commitment required.
The data rate is 15 Mbps, fast enough for Profibus, CAN, and RS-422 isolation links without bottlenecking the bus.
Yes. The supply voltage range of 4.5 V to 30 V includes 5 V rails, and the push-pull output drives CMOS and TTL inputs directly.
