LPC802M001JDH16FP
NXP USA Inc.
1.71V ~ 3.6VTube-40°C ~ 105°C (TA)
Ref. price$1.7800
Lead time on requestGet quote ›
NXP Semiconductors LPC8 Series
23 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors LPC8 Series series
The NXP Semiconductors NXP Semiconductors LPC8 Series series groups 23 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common core processor of ARM® Cortex®-M0+, core size of 32-Bit Single-Core and oscillator type of Internal. Variants differ by case, connectivity and mounting type, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors LPC8 Series part numbers are active and orderable.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 16-TSSOP (0.173\", 4.40mm Width) · 20-SOIC (0.295\", 7.50mm Width) · 20-TSSOP (0.173\", 4.40mm Width) · 24-TSSOP (0.173\", 4.40mm Width) · 32-VFQFN Exposed Pad
- Connectivity
- I2C, SPI, UART/USART · I²C, SPI, UART/USART
- Mounting type
- Surface Mount · Through Hole
- Number of i (O)
- 6 · 13 · 14 · 17 · 18 · 20 · 21 · 30
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C~85°C(TA) · -40°C~105°C(TA)
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tray · Tube
- Program memory size
- 4KB (4K x 8) · 16KB (16K x 8) · 32KB (32K x 8)
- RAM size
- 1K x 8 · 2K x 8 · 4K x 8
Variant comparison
| Parameter | LPC802M001JDH16FP | LPC802M001JDH20FP | LPC802M001JHI33E | LPC804M101JDH20FP | LPC804M101JDH24FP | LPC804M101JHI33E |
|---|---|---|---|---|---|---|
| Case | 16-TSSOP (0.173\", 4.40mm Width) | 20-TSSOP (0.173\", 4.40mm Width) | 32-VFQFN Exposed Pad | 20-TSSOP (0.173\", 4.40mm Width) | 24-TSSOP (0.173\", 4.40mm Width) | 32-VFQFN Exposed Pad |
| Connectivity | I²C, SPI, UART/USART | I²C, SPI, UART/USART | I2C, SPI, UART/USART | I²C, SPI, UART/USART | I²C, SPI, UART/USART | I²C, SPI, UART/USART |
| Mounting type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Number of i (O) | 13 | 17 | 17 | 17 | 21 | 30 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C~105°C(TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tube | Tube | Tray | Tube | Tube | Tray |
| Program memory size | 16KB (16K x 8) | 16KB (16K x 8) | 16KB (16K x 8) | 32KB (32K x 8) | 32KB (32K x 8) | 32KB (32K x 8) |
| RAM size | 2K x 8 | 2K x 8 | 2K x 8 | 4K x 8 | 4K x 8 | 4K x 8 |
Shared specifications
- Core processor
- ARM® Cortex®-M0+
- Core size
- 32-Bit Single-Core
- Oscillator type
- Internal
- Peripherals
- Brown-out Detect/Reset, POR, PWM, WDT
- Program memory type
- FLASH
Request a quote on any NXP Semiconductors LPC8 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
