TLV7011DCKR
Texas Instruments
Surface MountTape & Reel (TR); Cut Tape (CT)-40°C ~ 125°C
Ref. price$0.76
Lead time on requestGet quote
TLV7xxx Low-Dropout (LDO) Voltage Regulators
20 variants · Texas Instruments
About the TLV7xxx Low-Dropout (LDO) Voltage Regulators
The Texas Instruments TLV7xxx Low-Dropout (LDO) Voltage Regulators series groups 20 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common package of Tape & Reel (TR); Cut Tape (CT). Variants differ by case, current - quiescent and mounting, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 4-XDFN Exposed Pad · 4-XFBGA, DSBGA · 5-TSSOP, SC-70-5, SOT-353 · 6-TSSOP, SC-88, SOT-363 · 6-WFDFN · 8-VDFN Exposed Pad · 8-WFDFN Exposed Pad · 14-TSSOP (0.173\", 4.40mm Width) · SC-74A, SOT-753
- Current - quiescent
- 4.5 µA · 5µA · 9µA · 10µA · 18µA · 55 µA · 95 µA · 110 µA · 315nA · 900nA
- Mounting
- Surface Mount · Surface Mount, Wettable Flank
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 85°C (TJ) · -40°C ~ 125°C · -40°C ~ 125°C (TA) · -40°C ~ 125°C (TJ) · -40°C ~ 150°C (TJ)
- Output type
- Fixed · Open Drain · Open-Drain, Rail-to-Rail · Push-Pull · Push-Pull, Rail-to-Rail · Rail-to-Rail
- Output current
- 1A · 30mA · 33mA @ 5V · 40mA @ 5V · 150mA · 200mA
- CMRR, PSRR
- 73dB CMRR, 77dB PSRR · 75dB CMRR, 80dB PSRR · 78dB CMRR, 78dB PSRR
- Number of elements
- 1 · 2 · 4
Shared specifications
- Package
- Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | TLV7011DCKR | TLV7012DSGR | TLV7021DCKT | TLV7041DCKT | TLV7041QDBVRQ1 | TLV7044QPWRQ1 |
|---|---|---|---|---|---|---|
| Case | 5-TSSOP, SC-70-5, SOT-353 | 8-WFDFN Exposed Pad | 5-TSSOP, SC-70-5, SOT-353 | 5-TSSOP, SC-70-5, SOT-353 | SC-74A, SOT-753 | 14-TSSOP (0.173\", 4.40mm Width) |
| Current - quiescent | 5µA | 9µA | 10µA | 900nA | 900nA | 315nA |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C (TA) | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Output type | Push-Pull | Push-Pull, Rail-to-Rail | Open Drain | Open Drain | Open-Drain, Rail-to-Rail | Rail-to-Rail |
| Output current | — | 33mA @ 5V | — | — | 40mA @ 5V | — |
| CMRR, PSRR | 78dB CMRR, 78dB PSRR | 73dB CMRR, 77dB PSRR | 78dB CMRR, 78dB PSRR | 73dB CMRR, 77dB PSRR | 73dB CMRR, 77dB PSRR | 73dB CMRR, 77dB PSRR |
| Number of elements | 1 | 2 | 1 | 1 | 1 | 4 |
Request a quote on any TLV7xxx Low-Dropout (LDO) Voltage Regulators part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
