ADS1146IPW
Texas Instruments
TubeSPI-40°C ~ 105°C
Ref. price$7.54
Lead time on requestGet quote
Texas Instruments ADS1 Discrete Semiconductors Series
10 variants · Texas Instruments
About the Texas Instruments ADS1 Discrete Semiconductors Series
The Texas Instruments ADS1 Discrete Semiconductors Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, interface and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 16-TSSOP (0.173\", 4.40mm Width) · 16-VQFN Exposed Pad · 20-SSOP (0.154\", 3.90mm Width) · 20-TSSOP (0.173\", 4.40mm Width) · 24-VFQFN Exposed Pad · 28-SSOP (0.209\", 5.30mm Width) · 32-WFQFN Exposed Pad · 64-PowerTQFP
- Interface
- Serial · Serial, SPI · SPI
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 105°C · -40°C ~ 125°C
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT) · Tube
- Sampling rate (Per second)
- 2k · 6.25k · 20k · 32k · 40k · 100 · 144k
- Configuration
- ADC · MUX-ADC · MUX-PGA-ADC · PGA-ADC
- I/O channels
- 1 · 2 · 4 · 6 · 8
- Input type
- Differential · Differential, Single Ended
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | ADS1146IPW | ADS1205IRGET | ADS1213E | ADS1226IRGVT | ADS1254E | ADS1274IPAPT |
|---|---|---|---|---|---|---|
| Case | 16-TSSOP (0.173\", 4.40mm Width) | 24-VFQFN Exposed Pad | 28-SSOP (0.209\", 5.30mm Width) | 16-VQFN Exposed Pad | 20-SSOP (0.154\", 3.90mm Width) | 64-PowerTQFP |
| Interface | SPI | Serial | SPI | SPI | SPI | SPI |
| Operating temperature | -40°C ~ 105°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 105°C | -40°C ~ 85°C | -40°C ~ 125°C |
| Package | Tube | Tape & Reel (TR); Cut Tape (CT) | Bulk | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) |
| Sampling rate (Per second) | 2k | 40k | 6.25k | 100 | 20k | 144k |
| Configuration | MUX-PGA-ADC | — | PGA-ADC | MUX-ADC | MUX-ADC | ADC |
| I/O channels | 1 | — | 4 | 2 | 4 | 4 |
| Input type | Differential, Single Ended | — | Differential | Differential, Single Ended | Differential | Differential |
Request a quote on any Texas Instruments ADS1 Discrete Semiconductors Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
