NXP Semiconductors MC9S08 Series
66 variants · NXP Semiconductors
About the NXP Semiconductors MC9S08 Series
The NXP Semiconductors MC9S08 Series series groups 66 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of S08, core size of 8-Bit and mounting of Surface Mount. Variants differ by case, connectivity and number of i (O), so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 32-LQFP · 64-LQFP
- Connectivity
- I²C, LINbus, SCI, SPI · SCI
- Number of i (O)
- 25 · 57
- Operating temperature
- -40°C ~ 85°C (TA) · 0°C ~ 70°C (TA)
- Peripherals
- LCD, PWM, WDT · LVD, POR, PWM, WDT
- Program memory size
- 16KB (16K x 8) · 64KB (64K x 8)
- RAM size
- 1K x 8 · 4K x 8
- Speed
- 8MHz · 20MHz
Shared specifications
- Core processor
- S08
- Core size
- 8-Bit
- Mounting
- Surface Mount
- Oscillator type
- Internal
- Package
- Bulk
- Program memory type
- FLASH
- Voltage - supply (Vcc (Vdd))
- 1.8V ~ 3.6V
Variant comparison
| Parameter | MC9S08GW64CLH | MC9S08RE16FJE |
|---|---|---|
| Case | 64-LQFP | 32-LQFP |
| Connectivity | I²C, LINbus, SCI, SPI | SCI |
| Number of i (O) | 57 | 25 |
| Operating temperature | -40°C ~ 85°C (TA) | 0°C ~ 70°C (TA) |
| Peripherals | LCD, PWM, WDT | LVD, POR, PWM, WDT |
| Program memory size | 64KB (64K x 8) | 16KB (16K x 8) |
| RAM size | 4K x 8 | 1K x 8 |
| Speed | 20MHz | 8MHz |
Request a quote on any NXP Semiconductors MC9S08 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
