LT30xx LDO Regulators & Battery Chargers

5 variants · Analog DevicesAll Power Management (PMIC / Gate Driver) →

About the LT30xx LDO Regulators & Battery Chargers

ICBOMS is a China IC distributor and semiconductor supplier — an independent, Shenzhen-based overseas procurement agent for LT30xx LDO Regulators & Battery Chargers components — sourcing Analog Devices LT30xx LDO Regulators & Battery Chargers parts new and original only, across the authorized and vetted independent channel, with every lot authenticity-screened before shipment. The Analog Devices LT30xx LDO Regulators & Battery Chargers series groups 5 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting of Surface Mount and protection features of Over Current, Over Temperature, Reverse Polarity. Variants differ by case, number of regulators and operating temperature, so you can match the exact case your application requires using the selection guide below. All listed LT30xx LDO Regulators & Battery Chargers part numbers are active and orderable.

Select a variant by

Case: 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) Exposed Pad · 8-WFDFN Exposed Pad · 10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) Exposed Pad · 12-TSSOP (0.118\", 3.00mm Width) Exposed Pad
Number of regulators: 1 · 2
Operating temperature: -40°C ~ 125°C · -40°C ~ 140°C
Output configuration: Negative · Positive
Output current: 1.5A · 20mA · 50mA · 100mA · 100mA, 100mA
Output type: Adjustable · Fixed
Package: Tape & Reel (TR); Cut Tape (CT) · Tube
PSRR: 56dB (120Hz) · 58dB (120Hz) · 65dB (120Hz) · 70dB (120Hz) · 75dB (120Hz)

Shared specifications

Mounting: Surface Mount
Protection features: Over Current, Over Temperature, Reverse Polarity

Variant comparison

Parameter	LT3010HMS8E#TRPBF	LT3014BHVEDD#PBF	LT3015EMSE-5#PBF	LT3020EDD-1.8#PBF	LT3023EMSE#TRPBF
Case	8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) Exposed Pad	8-WFDFN Exposed Pad	12-TSSOP (0.118\", 3.00mm Width) Exposed Pad	8-WFDFN Exposed Pad	10-TFSOP, 10-MSOP (0.118\", 3.00mm Width) Exposed Pad
Number of regulators	1	1	1	1	2
Operating temperature	-40°C ~ 140°C	-40°C ~ 125°C	-40°C ~ 125°C	-40°C ~ 125°C	-40°C ~ 125°C
Output configuration	Positive	Positive	Negative	Positive	Positive
Output current	50mA	20mA	1.5A	100mA	100mA, 100mA
Output type	Adjustable	Adjustable	Fixed	Fixed	Adjustable
Package	Tape & Reel (TR); Cut Tape (CT)	Tube	Tube	Tube	Tape & Reel (TR); Cut Tape (CT)
PSRR	75dB (120Hz)	70dB (120Hz)	58dB (120Hz)	56dB (120Hz)	65dB (120Hz)

Request a quote on any LT30xx LDO Regulators & Battery Chargers part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
