STMicroelectronics IPS1 Series

6 variants · STMicroelectronics

About the STMicroelectronics STMicroelectronics IPS1 Series series

The STMicroelectronics STMicroelectronics IPS1 Series series groups 6 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common features of -, input type of Non-Inverting and mounting type of Surface Mount. Variants differ by case, current - output and fault protection, so you can match the exact case your application requires using the selection guide below. All listed STMicroelectronics IPS1 Series part numbers are active and orderable.

Select a variant by

Case
24-PowerBSOP (0.295\", 7.50mm Width) · 48-VFQFN Exposed Pad
Current - output
- · 2.4A · 5A · 5.6A
Fault protection
Current Limiting (Adjustable), Open Load Detect, Over Temperature, Reverse Current, UVLO · Current Limiting (Fixed), Over Load, Over Temperature, Reverse Current, Short Circuit, UVLO · Current Limiting (Fixed), Over Load, Over Temperature, UVLO · Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit, UVLO
Interface
Logic · On/Off
Operating temperature
-40°C ~ 150°C · -40°C~150°C
Package
Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Voltage - load
- · 8.65V ~ 60V
Voltage - supply (Vcc (Vdd))
8V ~ 60V · 8.65V ~ 60V · Not Required

Variant comparison

ParameterIPS1025HFQIPS1025HFTRIPS1025HQIPS1025HQ-32IPS1025HTRIPS1025HTR-32
Case48-VFQFN Exposed Pad24-PowerBSOP (0.295\", 7.50mm Width)48-VFQFN Exposed Pad48-VFQFN Exposed Pad24-PowerBSOP (0.295\", 7.50mm Width)24-PowerBSOP (0.295\", 7.50mm Width)
Current - output2.4A-2.4A5.6A5A5A
Fault protectionCurrent Limiting (Fixed), Over Load, Over Temperature, UVLOCurrent Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit, UVLOCurrent Limiting (Fixed), Over Load, Over Temperature, Reverse Current, Short Circuit, UVLOCurrent Limiting (Fixed), Over Load, Over Temperature, Reverse Current, Short Circuit, UVLOCurrent Limiting (Adjustable), Open Load Detect, Over Temperature, Reverse Current, UVLOCurrent Limiting (Adjustable), Open Load Detect, Over Temperature, Reverse Current, UVLO
InterfaceLogicOn/OffLogicLogicLogicLogic
Operating temperature-40°C~150°C-40°C ~ 150°C-40°C ~ 150°C-40°C~150°C-40°C~150°C-40°C~150°C
PackageTape & Reel (TR); Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)Tape & Reel (TR); Cut Tape (CT)
Voltage - load8.65V ~ 60V-----
Voltage - supply (Vcc (Vdd))Not Required8.65V ~ 60V8V ~ 60V8V ~ 60V8V ~ 60V8V ~ 60V

Shared specifications

Features
-
Input type
Non-Inverting
Mounting type
Surface Mount
Number of outputs
1
Output configuration
High Side
Output type
N-Channel
Ratio - Input:Output
1:1
Rds on
12mOhm
Switch type
General Purpose
