Omron EE-SX474 Through-Beam Slot Sensor, NPN Light-ON, 5 V

MPNEE-SX474
Active

Omron EE-SX474, through-beam slot optical sensor, NPN open-collector Light-ON output, 5 V supply, 5 mm sensing gap, chassis-mount package, active production.

$34.46Ref. price · indicative, final on quote
EE-SX474 datasheet
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

EE-SX474 Technical Specifications
ParameterValue
Mounting_typeChassis Mount
Operating temperature high-25°C to 55°C(TA)
Output_typeNPN - Open Collector/Light-ON
Package_typeTray
Sensing_typeThrough-Beam
Product_statusActive
Supply_voltage_v5.0
Switching_current_a0.035
Sensing_distance_max_mm0.197

Product details

The Omron EE-SX474 is a through-beam slot-type optical sensor with a 5 mm sensing gap. Output is NPN open-collector, active when the beam is uninterrupted (Light-ON). It runs on a 5 V supply and draws 35 mA max switching current. The housing is chassis-mount, suited for fixed position sensing on conveyors, edge detection, or flag presence in light industrial equipment.

5 V supply — not a 12 V drop-in

Rated supply is 5 V. The slot gap is 5 mm — enough for a standard PCB edge or a thin flag, but tight for thicker media. Operating temperature range is -25°C to 55°C, so it stays inside for factory-floor use; not rated for outdoor or high-temp enclosures.

Active, no end-of-life notice

Marked Active on lifecycle. No LTB or EOL notice on record.

Frequently asked questions

What is the output type of EE-SX474?

NPN open-collector, Light-ON — output transistor turns on when the slot beam is uninterrupted.

Is EE-SX474 compatible with 12 V supply?

No — the rated supply is 5 V. Operating outside this range may damage the sensor or cause erratic switching.

What is the difference between EE-SX474 and EE-SX470?

The EE-SX470 is a different variant; the EE-SX474 uses a 5 mm slot with NPN Light-ON output. Check the specific datasheet for the EE-SX470 to compare slot width and output logic.

Is there a direct substitute for EE-SX474?

The EE-SPX305-W2A is a through-beam NPN open-collector sensor with the same 5 mm gap and 5 V supply, but its output is Dark-ON and operating temperature range is -10°C to 55°C. Verify wiring logic before substituting.
