Nisshinbo Micro Devices Inc. — DC-DC Power Modules

Nisshinbo Micro Devices Inc. DC-DC Power Modules — 15 part numbers with specifications and datasheets. Filter by key specs and request a quote on ICBOMS.

Supplier Device Package
SOT-23-5 (MTP5) · 6-HSON (2.9x2.8) · TSOT-23-6 · SC-82AB
Package / Case
SC-74A, SOT-753 · 6-SMD, Flat Lead Exposed Pad · SOT-23-6 Thin, TSOT-23-6 · SC-82A, SOT-343
Current - Output
100 mA · 1A · 700mA (Switch) · 35mA
Voltage - Output (Min/Fixed)
2.495V · 1V · 2.7V · 5V
Voltage Dropout (Max)
0.075V @ 1mA · 0.38V @ 1mA · 0.53V @ 1mA · 0.19V @ 300mA
Current - Quiescent (Iq)
100 µA · 3.9 µA · 3.3 µA · 70 µA
Voltage - Input (Max)
6V · 5.5V · 10V · 5.25V
Operating Temperature
-40°C ~ 125°C · -40°C ~ 85°C · -40°C ~ 85°C (TA) · -40°C ~ 105°C (TA)
