Eaton - Electronics Division — Supercapacitors

Turnkey BOM procurement and spot-buy shortage sourcing for Eaton - Electronics Division Supercapacitors — 11 part numbers with specifications and datasheets. Filter

Capacitance
1 F · 100 mF · 1.5 F · 220 mF
ESR (Equivalent Series Resistance)
200mOhm @ 100Hz · 75Ohm @ 1kHz · 30Ohm · 30Ohm @ 1kHz
Height - Seated (Max)
0.532" (13.50mm) · 0.256" (6.50mm) · 0.280" (7.10mm) · 0.197" (5.00mm)
Size / Dimension
0.315" Dia (8.00mm) · 0.531" Dia (13.50mm) · 0.846" Dia (21.50mm) · 0.453" Dia (11.50mm)
Lead Spacing
0.138" (3.50mm) · 0.197" (5.00mm) · 0.394" (10.00mm) · 0.787" (20.00mm)
Operating Temperature
-40°C~65°C · -25°C~70°C · -25°C ~ 70°C
Package / Case
Radial, Can · Axial, Can - Horizontal · Axial, Can - Vertical
Lifetime @ Temp.
1000 Hrs @ 65°C · 1000 Hrs @ 70°C
