Alpha & Omega Semiconductor Inc. — Discrete Semiconductors

Turnkey BOM procurement and spot-buy shortage sourcing for Alpha & Omega Semiconductor Inc. Discrete Semiconductors — 3 part numbers with specifications and

Gate Charge (Qg) (Max) @ Vgs
7 nC @ 4.5 V · 14 nC @ 10 V · 12.2 nC @ 4.5 V · 4.34 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds
630 pF @ 15 V · 645 pF @ 15 V · 1200 pF @ 15 V · 390 pF @ 15 V
Rds On (Max) @ Id, Vgs
28mOhm @ 5.8A, 10V · 26.5mOhm @ 5.7A, 10V · 50mOhm @ 4A, 10V · 44mOhm @ 4.3A, 10V
Vgs(th) (Max) @ Id
1.45V @ 250µA · 1.5V @ 250µA · 1.3V @ 250µA · 1.4V @ 250µA
Current - Continuous Drain (Id) @ 25°C
5.8A (Ta) · 5.7A (Ta) · 4A (Ta) · 5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)
2.5V, 10V · 4.5V, 10V · 1.5V, 4.5V · 5V, 20V
Package
Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Bulk
Vgs (Max)
±12V · ±20V · ±8V · ±25V
