DRV8144ASQRYJRQ1
Texas Instruments
Surface Mount, Wettable FlankTape & Reel (TR); Cut Tape (CT)SPI
Ref. price$5.88
Lead time on requestGet quote
Texas Instruments DRV8 Microcontrollers Series
6 variants · Texas Instruments
About the Texas Instruments DRV8 Microcontrollers Series
The Texas Instruments DRV8 Microcontrollers Series series groups 6 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by case, mounting and operating temperature, so you can match the exact case your application requires using the selection guide below. All listed Texas Instruments DRV8 Microcontrollers Series part numbers are active and orderable.
Select a variant by
- Case
- 16-PowerTSSOP (0.173\", 4.40mm Width) · 16-PowerVFQFN · 16-VFQFN Exposed Pad · 28-PowerTSSOP (0.173\", 4.40mm Width) · 48-PowerTQFP
- Mounting
- Surface Mount · Surface Mount, Wettable Flank
- Operating temperature
- -40°C ~ 125°C (TA) · -40°C ~ 150°C (TJ)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 0V ~ 5.5V · 4.5V ~ 5.5V · 4.9V ~ 37V · 8V ~ 38V
- Interface
- Parallel · PWM · SPI · Step/Direction
- Output configuration
- Half Bridge · Half Bridge (2)
- Output current
- 2.5A · 2.8A · 3.5A · 30A · 46A
Variant comparison
| Parameter | DRV8424PWPR | DRV8800PWP | DRV8876RGTR | DRV8144ASQRYJRQ1 | DRV8145HQRXZRQ1 | DRV8714HQPHPRQ1 |
|---|---|---|---|---|---|---|
| Case | 28-PowerTSSOP (0.173\", 4.40mm Width) | 16-PowerTSSOP (0.173\", 4.40mm Width) | 16-VFQFN Exposed Pad | 16-PowerVFQFN | 16-VFQFN Exposed Pad | 48-PowerTQFP |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount, Wettable Flank | Surface Mount | Surface Mount |
| Operating temperature | -40°C ~ 125°C (TA) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 150°C (TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Voltage | 0V ~ 5.5V | 8V ~ 38V | 0V ~ 5.5V | 0V ~ 5.5V | 4.5V ~ 5.5V | 4.9V ~ 37V |
| Interface | Step/Direction | Parallel | PWM | SPI | SPI | — |
| Output configuration | Half Bridge (2) | Half Bridge (2) | Half Bridge (2) | Half Bridge | Half Bridge | — |
| Output current | 2.5A | 2.8A | 3.5A | 30A | 46A | — |
Request a quote on any Texas Instruments DRV8 Microcontrollers Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
