DRV8143SQRXYRQ1
Texas Instruments
Surface Mount, Wettable FlankTape & Reel (TR); Cut Tape (CT)PWM, SPI
Ref. price$6.25
Lead time on requestGet quote
Texas Instruments DRV8 Dc Dc Modules Series
9 variants · Texas Instruments
About the Texas Instruments DRV8 Dc Dc Modules Series
The Texas Instruments DRV8 Dc Dc Modules Series series groups 9 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by case, mounting and operating temperature, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-PowerSOIC (0.154\", 3.90mm Width) · 14-VFQFN · 16-VFQFN Exposed Pad · 20-TSSOP (0.173\", 4.40mm Width) · 24-PowerTSSOP (0.173\", 4.40mm Width) · 28-PowerTSSOP (0.173\", 4.40mm Width) · 28-VFQFN Exposed Pad · SOT-563, SOT-666
- Mounting
- Surface Mount · Surface Mount, Wettable Flank
- Operating temperature
- -40°C ~ 125°C (TA) · -40°C ~ 150°C (TJ)
- Package
- Tape & Reel (TR) · Tape & Reel (TR); Cut Tape (CT)
- Voltage
- 0V ~ 5.5V · 4.5V ~ 18V · 4.5V ~ 33V · 4.5V ~ 35V · 5V ~ 20V · 8.2V ~ 45V
- Interface
- Logic · PWM · PWM, SPI · SPI
- Motor type - stepper
- Bipolar · Unipolar
- Output configuration
- Half Bridge · Half Bridge (2) · Half Bridge (4)
Variant comparison
| Parameter | DRV8143SQRXYRQ1 | DRV8231ADDAR | DRV8300NPWR | DRV8424PPWPR | DRV8145SQRXZRQ1 | DRV8220DRLR |
|---|---|---|---|---|---|---|
| Case | 14-VFQFN | 8-PowerSOIC (0.154\", 3.90mm Width) | 20-TSSOP (0.173\", 4.40mm Width) | 28-PowerTSSOP (0.173\", 4.40mm Width) | 16-VFQFN Exposed Pad | SOT-563, SOT-666 |
| Mounting | Surface Mount, Wettable Flank | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating temperature | -40°C ~ 125°C (TA) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Voltage | 4.5V ~ 35V | 4.5V ~ 33V | 5V ~ 20V | 0V ~ 5.5V | 4.5V ~ 35V | 4.5V ~ 18V |
| Interface | PWM, SPI | PWM | — | PWM | PWM, SPI | PWM |
| Motor type - stepper | Bipolar | Bipolar | — | Bipolar | Bipolar | Bipolar |
| Output configuration | Half Bridge | Half Bridge (2) | — | Half Bridge (2) | Half Bridge | Half Bridge (2) |
Request a quote on any Texas Instruments DRV8 Dc Dc Modules Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
