Texas Instruments LMK5C33216RGCR — Clock & Timing ICs

LMK5C33216RGCR Clock Generator, Jitter Attenuator, 3 GHz Max

MPNLMK5C33216RGCR
Active

Texas Instruments LMK5C33216RGCR, Clock Generator / Synchronizer / Jitter Attenuator, single PLL, 3:16 input:output ratio, 3 GHz max output, 3.135V–3.465V supply, -40°C to 85°C, 64-VFQFN exposed pad.

$37.5000Ref. price · indicative, final on quote
Texas Instruments LMK5C33216RGCR datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

LMK5C33216RGCR specifications
ParameterValue
TypeClock Generator, Clock Synchronizer, Jitter Attenuator
MountingSurface Mount
Voltage3.135V ~ 3.465V
Frequency200MHz, 1GHz, 3GHz
Operating temperature-40°C ~ 85°C
PLLYes
InputHCSL, LVCMOS, LVDS, LVPECL, Crystal
OutputCML, LVCMOS, LVDS, LVPECL
PackageTape & Reel (TR)
Case64-VFQFN Exposed Pad
Divider (Multiplier)Yes/No
Number of circuits1
Ratio - Input:Output3:16
Differential - Input:OutputYes/Yes

Product details

Three jobs, one 64-pin package

It accepts HCSL, LVCMOS, LVDS, LVPECL, or crystal inputs and delivers CML, LVCMOS, LVDS, or LVPECL outputs across a 3:16 fanout from a single PLL core.

Output frequency ceiling — three rails

The maximum output frequency is specified at three tiers: 200 MHz, 1 GHz, and 3 GHz, depending on the output format and divider path selected. That 3 GHz top end puts this part in the range for 100G/400G line-card reference clocks or high-speed ADC/DAC sampling clocks where the jitter floor matters more than the raw frequency.

Package and mounting — 64-VFQFN with exposed pad

Housed in a 64-VFQFN exposed-pad package (9x9 mm body), surface-mount only.

Frequently asked questions

Is LMK5C33216RGCR pin-compatible with LMK5C33216RGCT?

The suffix RGCR vs RGCT indicates different tape-and-reel packaging options, not a pinout change. Both share the same 64-VFQFN package and are functionally identical — the RGCR is the standard reel quantity, RGCT is a smaller reel.

Does LMK5C33216RGCR require an external loop filter?

The device integrates the loop filter components internally for the PLL — no external RC network needed on the board. This saves board area and simplifies the layout versus older PLL clock generators.

Is LMK5C33216RGCR compatible with LVDS inputs?

Yes, LVDS is one of the accepted input formats alongside HCSL, LVCMOS, LVPECL, and crystal.
