MC9S12DG256MPVE
NXP Semiconductors
HCS12TrayPWM, WDT
Ref. price$48.61
Lead time on requestGet quote
NXP Semiconductors MC9S12 Series
14 variants · NXP Semiconductors
About the NXP Semiconductors MC9S12 Series
The NXP Semiconductors MC9S12 Series series groups 14 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core size of 16-Bit, EEPROM size of 4K x 8 and mounting of Surface Mount. Variants differ by case, connectivity and core processor, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 80-QFP · 112-LQFP
- Connectivity
- CANbus, EBI/EMI, I²C, IrDA, SCI, SPI · CANbus, I²C, SCI, SPI
- Core processor
- HCS12 · HCS12X
- Data converters
- A/D 12x12b · A/D 16x10b
- Number of i (O)
- 59 · 91
- Oscillator type
- External · Internal
- Peripherals
- LVD, POR, PWM, WDT · PWM, WDT
- RAM size
- 12K x 8 · 16K x 8
Shared specifications
- Core size
- 16-Bit
- EEPROM size
- 4K x 8
- Mounting
- Surface Mount
- Operating temperature
- -40°C ~ 125°C (TA)
- Package
- Tray
- Program memory size
- 256KB (256K x 8)
- Program memory type
- FLASH
Variant comparison
| Parameter | MC9S12DG256MPVE | MC9S12XET256MAA |
|---|---|---|
| Case | 112-LQFP | 80-QFP |
| Connectivity | CANbus, I²C, SCI, SPI | CANbus, EBI/EMI, I²C, IrDA, SCI, SPI |
| Core processor | HCS12 | HCS12X |
| Data converters | A/D 16x10b | A/D 12x12b |
| Number of i (O) | 91 | 59 |
| Oscillator type | Internal | External |
| Peripherals | PWM, WDT | LVD, POR, PWM, WDT |
| RAM size | 12K x 8 | 16K x 8 |
Request a quote on any NXP Semiconductors MC9S12 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
