What the MPX2200D is and where it fits
The NXP MPX2200D is a differential pressure sensor from the MPX2200 series, delivering a ratiometric Wheatstone bridge output of 0 mV to 40 mV at a 10 V excitation. It is designed for board-mount applications requiring a through-hole module with PC pin termination. The sensor is temperature compensated, which reduces the need for external calibration across the operating range.
Pressure range and signal level — what they mean for your design
Rated for a differential operating pressure of 29.01 PSI (200 kPa), with a maximum overpressure of 116.03 PSI (800 kPa) before damage. The 0 mV to 40 mV full-scale output at 10 V excitation is a low-level signal that typically requires an instrumentation amplifier or a precision ADC with a suitable gain stage. The ±0.25% accuracy figure applies across the compensated temperature range, making this a repeatable transducer for industrial pressure monitoring, pneumatic controls, and HVAC differential pressure sensing.
Supply voltage and temperature grade
Operates from a 10 V to 16 V supply. The -40°C to 125°C temperature range covers industrial and under-hood automotive environments.
